Single Phase Low
Voltage
Three Phase Low
Voltage
Model AVD3 430
Low Voltage:
208-240 VAC
Model AVD3 430
Low Voltage:
208-240 VAC
WARNING: Keep hands away from components.
CAUTION: RISK OF ELECTRIC SHOCK. The bus capacitors
discharge to a level below 50V DC in 1 minute.
WARNING: DO NOT RUN FANS WITHOUT AIRFOILS. THE FANS ARE
NOT CONFIGURED TO OPERATE WITHOUT AIRFOILS ATTACHED.
WHEN CYCLING INCOMING POWER, WAIT ONE (1)
MINUTE BEFORE TURNING THE POWER BACK ON!
Note: Make sure the fan is run only when the cover is reinstalled.
The drive should only be operated in a pollution degree two (2)
environment, which is achieved with the bottom cover on.
4.1.1 Drive Installation
Low Voltage
L1 L2 L3
Neutral/Live
Live
To Next Page
