© 2019 EnergyLogic, LLC Toll Free: 800 311 8828 Fax: 615 471 5202 www.energylogic.com 53
Rev. Date 040819
Three Phase High
Voltage
Model AVD3 430
High Voltage:
380-480 VAC
WARNING: Keep hands away from components.
CAUTION: RISK OF ELECTRIC SHOCK. The bus capacitors
discharge to a level below 50V DC in 1 minute.
4.1.2 Drive Installation
High Voltage
WARNING: DO NOT RUN FANS WITHOUT AIRFOILS. THE FANS ARE
NOT CONFIGURED TO OPERATE WITHOUT AIRFOILS ATTACHED.
WHEN CYCLING INCOMING POWER, WAIT ONE (1)
MINUTE BEFORE TURNING THE POWER BACK ON!
Note: Make sure the fan is run only when the cover is reinstalled.
The drive should only be operated in a pollution degree two (2)
environment, which is achieved with the bottom cover on.
