3. Guy Wire Installation
Guy Wire Assembly
Wire Rope (4)
19ft (A), 23ft (B),
or 33ft (C)
Turn Buckle (4)
1/4" Quicklink (4)
Wire Rope Clamp (8)
45°
Required for both the Fixed Angle Mount and the Universal Mount.
