Components (Universal Mount)
AVD 3 Motor
Unit (1)
Airfoil (3)
I-Beam Shim (2)
I-Beam Clamp (2)
Wire Rope Clamp (2)
Safety Cable Parts
Wire Rope 3/16” (1)
5/16"-24 x 2"
Hex Bolt (6)
5/16" Washer (12)
5/16"-24 Nylon
Lock Nut (6)
3 Blade Bolt Kit
Make sure all parts listed above are included if you purchased the Universal Mount.
Read the entire manual before beginning the installation of the fan. Additional parts
may be required, including, but not limited to, guy wire attachment hardware, extra
cable, Unistrut, and bolts for Glulam mounting. Power cable is not provided.
Guy Wire Assembly
Wire Rope (4)
19ft (A), 23ft (B),
or 33ft (C)
Turn Buckle (4)
1/4" Quicklink (4)
Wire Rope Clamp (8)
Guy Wire
Elastic Band (1)
Elastic Band
Clip (1)
Touchpad Digital
Remote (1)
Stranded Shielded CAT5e (1)
RJ45
Pin-Out
Type “B”
Extension Tube (1)
Universal Mount (1)
Guy Wire
Bracket (2)
Glulam Bracket (2)
(Optional)
3/8" Washer (4)
3/8"-16 Nylon Lock Nut (4)
3/8"-16 x 2 3/4" Hex
Head Bolts (4)
3/8" Washer (8)
Extension Bolt Kit
1/2"-13 x 2 1/2" Hex Bolt (4)
1/2"-13 Nylon Lock Nut (4)
1/2" Washer (8)
I-Beam Bolt Kit
