© 2019 EnergyLogic, LLC Toll Free: 800 311 8828 Fax: 615 471 5202 www.energylogic.com 22
Rev. Date 040819
1.1.3 Fixed Angle Mount Unistrut
This method is used to span components of a
building structure. Attachment points to the
building structure can vary greatly, so we
recommend contacting Unistrut so they can
recommend the best method for attaching the
Unistrut (www.unistrut.us).
If the spanning distance is greater than 8 feet,
please consult a Structural Engineer. Please
refer to page 4 for the maximum torque and
weight values.
NOTE: Mounting to C- and Z-purlins requires Unistrut span
mounting. Mounting to trusses under three (3) inches in width
requires two or more trusses to be linked with Unistrut.
