L3 L2 L1
Remove six (6) screws and the bottom cover. Be careful not to
damage the electrical components with the cover removed.
6x
2.3 All Universal Mounts
Motor Unit
WARNING: The fan must be lifted by the struts. Do NOT lift the fan by the drive.
Two people can lift the fan if a lift is not available.
Must use Guy Wire Brackets when installing the Universal Mount
