© 2019 EnergyLogic, LLC Toll Free: 800 311 8828 Fax: 615 471 5202 www.energylogic.com 64
Rev. Date 040819
7.2 Touchpad Remote Operation
Screens:
A - Home Screen
B - Fault Code Screen
C - Operating Hours Screen
D - Fan Diameter Selection Screen
Instructions:
6.2.1: Once the fan is powered on, click the forward button and increase the speed by clicking the
up button. The fan will do an initial blade detection: spinning in reverse to 10 RPM, accelerating
for a few seconds, and then the fan will have recognized the fan diameter. It will then slow down
and resume the commanded direction and speed (this operation will occur every time that the
incoming power to the fan is cycled).
6.2.2: If the fan stops operating unexpectedly, navigate to the fault code screen and record any
fault codes (if present). Click the reset button until the display reads ‘0’ or none. Then, attempt
to run the fan again. If the fan is still not operating, navigate to the fault code screen via the
navigation arrows at the bottom of the screen and document the code(s) displayed and call
technical support at 866-668-3247.
6.2.3: To view your fan’s operating hours, navigate from the home screen to the far right screen.
B
C
E
A
To Next Page
