MacroAir Technologies EnergyLogic AVD3 User Manual

© 2019 EnergyLogic, LLC Toll Free: 800 311 8828 Fax: 615 471 5202 www.energylogic.com 9
Rev. Date 040819
AirVolution-D3
The AirVolution-D3 has a standard airfoil to mount clearance of 3 feet [0.920 m] with the Fixed
Angle Mount. A clearance of 2 feet [0.6 m] is the minimum allowed clearance. Refer to the Fan
Clearance & Placement charts on pages 6-8 for required fan clearance and mounting conditions.
Fan Dimensions
3.667
12'-0"
1.060
3'-6"
0.920
3'-0"
ILLUSTRATION
SHOWN WITH
STANDARD EXTENSION
0.721
2'-4"
12' AirVolutionD-3
A-01
DO NOT SCALE DRAWING
MA12XL4303
SHEET 1 OF 1
1/21/2015
1/21/2015
1/21/2015
xxxx
xxxx
xxxx
xxxx
MD
JH
EV
UNLESS OTHERWISE SPECIFIED:
SCALE: 1:36
WEIGHT:
REV
DWG. NO.
A
SIZE
TITLE:
MacroAir
794 S Allen St. San Bernardino, CA 92408
NAME
DATE
COMMENTS:
Q.A.
MFG APPR.
ENG APPR.
CHECKED
DRAWN
FINISH
MATERIAL
INTERPRET GEOMETRIC
TOLERANCING PER:
DIMENSIONS ARE IN INCHES
TOLERANCES:
FRACTIONAL
.010
ANGULAR: MACH
1 BEND 1
TWO PLACE DECIMAL .01
THREE PLACE DECIMAL
.001
PROPRIETARY AND CONFIDENTIAL
THE INFORMATION CONTAINED IN THIS
DRAWING IS THE SOLE PROPERTY OF
MacroAir TECHNOLOGIES. ANY
REPRODUCTION IN PART OR AS A WHOLE
WITHOUT THE WRITTEN PERMISSION OF
MacroAir TECHNOLOGIES IS
PROHIBITED.
5
4
3
2
1
