30 ft-lbs
[41 N-m]
9/16”
1.3 All Fixed Angle Mounts
Motor Unit
Do not bend rubber boot
WARNING: Do not put too much tension on the safety cable. This will
deform the rubber boot and hinder the proper cooling of the motor.
Universal Mount I-Beam safety cable starts on page 29
Universal Mount Glulam safety cable starts on page 30
Universal Mount Unistrut safety cable starts on page 31
