Magnetrol Eclipse 706GWR - Quickstart Menu Options

10
57-606 ECLIPSE Model 706 Guided Wave Radar Transmitter
Level Units Select the Units of measurement for the level readout:
• Inches • Feet • Millimeters • Centimeters • Meters
Probe Model Select the Probe Model to be used with Model 706:
(NOTE: All Probe Models may not be available depending on the firmware version.)
• 7YD Coaxial High Temperature High Pressure
• 7YF Single Rod for installation onto tanks
• 7YG Single Rod for installation into cages
• 7YH Single Hygienic (Future)
• 7YJ Single High Temperature High Pressure for cages
• 7YL Single Rod High Pressure for cages
• 7YM Single Rod High Pressure for tanks
• 7YN Single Rod High Temperature High Pressure for tanks
• 7YP Coaxial High Pressure
• 7YS Coaxial Steam
• 7YT Coaxial Standard
• 7YV Coax High Vibration (Future)
• 7Y1 Single Flexible Standard
• 7Y2 Single Flexible Bulk Solids
• 7Y3 Single Flexible Standard High Temperature High Pressure
• 7Y5 Twin Flexible Bulk Solids
• 7Y6 Single Flexible High Temperature High Pressure for Cages
• 7Y7 Twin Flexible with FEP Coating
Probe Mount Select the type of Probe Mounting to the vessel:
(NOTE: All Probe Mount options may not be available depending on the firmware version).
• NPT (National Pipe Thread)
• BSP (British Standard Pipe)
• Flange (ANSI or DIN)
• NPT with Flushing Connection
• BSP with Flushing Connection
• Flange with Flushing Connection
• Hygienic
Probe Length Enter the exact Probe Length as printed on the probe nameplate. Probe Length is shown
as the last three digits of the Probe Model number. Range is 12 inches to 100 feet (30 cm
to 30 meters) probe dependent. Refer to Section 1.4.1.1.
Level Offset Enter the desired level reading when the liquid is at the end of the probe. Range is -25 feet
to 75 feet (-762 cm to 22 meters). Refer to Section 3.4 for further information. (With default
Level Offset = 0, all measurements are referenced from the bottom of the probe.)
Dielectric Range Enter the Dielectric Range for the material to be measured.
Below 1.7 (Light Hydrocarbons like Propane and Butane)
1.7 to 3.0 (Most typical hydrocarbons)
3.0 to 10 (Varying dielectric, for example: mixing tanks)
Above 10 (Water-based media)
HART Only
4 mA Set Point
(LRV)
Enter the level value (0%-point) for the 4 mA point. Lower Range Value (LRV).
Refer to Section 1.4.1.1.
20 mA Set Point
(URV)
Enter the level value (100%-point) for the 20 mA point. Upper Range Value (URV).
Refer to Section 1.4.1.1.
Failure Alarm
Enter the desired output state when a Failure Indicator is active.
• 22 mA
• 3.6 mA
• Hold (Hold last value is not recommended)
1.4.1 QuickStart Menu Options
