Magnetrol Eclipse 706GWR - Small Coaxial Probe

84
57-606 ECLIPSE Model 706 Guided Wave Radar Transmitter
7
12 3 456 7 8 910 11 12 13 14 15
1 | TECHNOLOGY
2 | MEASUREMENT SYSTEM
3 | CONFIGURATION/STYLE (RIGID)
7 ECLIPSE GWR Probes - Model 706
A English
C Metric
D Small Coaxial, High Temp/High Pressure: Overfill w/Glass Seal (+850 °F/+450 °C) — Only available with 10th digit N or D
P Small Coaxial, High Pressure: Overfill w/Glass Seal (+400 °F/+200 °C) — Only available with 10th digit N or D
S Small Coaxial, Saturated Steam +575/650 °F (+300/345 °C), Max. Length = 240” (610 cm) — Only available with 10th digit N, 9th digit 2 or 3
T Small Coaxial, Overfill Standard O-Ring Seal (+400 °F/+200 °C) — NOT available with 10th digit N or D
4 5 | PROCESS CONNECTION – SIZE/TYPE (consult factory for other process connections)
Threaded
1 1
3
⁄4" NPT Thread ¬
2 2
1" BSP (G1) Thread ¬
¿ Confirm mounting conditions/nozzle diameter to ensure sufficient clearance.
¡ Always check dimensions if ANSI/EN flanges are not used.
¬ Not available with 3rd Digit D
√ Not available with 3rd Digit D or P
EN Flanges
B B
DN 25, PN 16/25/40 EN 1092-1 TYPE A ¿ ¬
B C
DN 25, PN 63/100 EN 1092-1 TYPE B2 ¿ ¬
C B
DN 40, PN 16/25/40 EN 1092-1 TYPE A ¬
C C
DN 40, PN 63/100 EN 1092-1 TYPE B2 ¬
C F
DN 40, PN 160 EN 1092-1 TYPE B2 ¬
C G
DN 40, PN 250 EN 1092-1 TYPE B2 ¬
C H
DN 40, PN 320 EN 1092-1 TYPE B2 ¬
C J
DN 40, PN 400 EN 1092-1 TYPE B2 ¬
D A DN 50, PN 16 EN 1092-1 TYPE A
D B DN 50, PN 25/40 EN 1092-1 TYPE A
D D DN 50, PN 63 EN 1092-1 TYPE B2
D E DN 50, PN 100 EN 1092-1 TYPE B2
D F
DN 50, PN 160 EN 1092-1 TYPE B2
D G
DN 50, PN 250 EN 1092-1 TYPE B2
D H
DN 50, PN 320 EN 1092-1 TYPE B2
D J
DN 50, PN 400 EN 1092-1 TYPE B2
E A DN 80, PN 16 EN 1092-1 TYPE A
E B DN 80, PN 25/40 EN 1092-1 TYPE A
E D DN 80, PN 63 EN 1092-1 TYPE B2
E E DN 80, PN 100 EN 1092-1 TYPE B2
E F DN 80, PN 160 EN 1092-1 TYPE B2
E G DN 80, PN 250 EN 1092-1 TYPE B2
E H DN 80, PN 320 EN 1092-1 TYPE B2
E J DN 80, PN 400 EN 1092-1 TYPE B2
F A DN 100, PN 16 EN 1092-1 TYPE A
F B DN 100, PN 25/40 EN 1092-1 TYPE A
F D DN 100, PN 63 EN 1092-1 TYPE B2
F E DN 100, PN 100 EN 1092-1 TYPE B2
F F DN 100, PN 160 EN 1092-1 TYPE B2
F G DN 100, PN 250 EN 1092-1 TYPE B2
F H DN 100, PN 320 EN 1092-1 TYPE B2
F J DN 100, PN 400 EN 1092-1 TYPE B2
ANSI Flanges
2 3
1" 150# ANSI RF ¿ √
2 4
1" 300# ANSI RF ¿ √
2 5
1" 600# ANSI RF ¿ √
2 K
1" 600# ANSI RTJ ¿ √
3 3
1
1
⁄2" 150# ANSI RF √
3 4
1
1
⁄2" 300# ANSI RF √
3 5
1
1
⁄2" 600# ANSI RF √
3 K
1
1
⁄2" 600# ANSI RTJ √
3 7
1
1
⁄2" 900/1500# ANSI RF√
3 M
1
1
⁄2" 900/1500# ANSI RTJ√
3 8
1
1
⁄2" 2500# ANSI RF √
3 N
1
1
⁄2" 2500# ANSI RTJ √
4 3
2" 150# ANSI RF
4 4
2" 300# ANSI RF
4 5
2" 600# ANSI RF
4 7
2" 900/1500# ANSI RF
4 8
2" 2500# ANSI RF
4 K
2" 600# ANSI RTJ
4 M
2" 900/1500# ANSI RTJ
4 N
2" 2500# ANSI RTJ
5 3
3" 150# ANSI RF
5 4
3" 300# ANSI RF
5 5
3" 600# ANSI RF
5 6
3" 900# ANSI RF
5 7
3" 1500# ANSI RF
5 8
3" 2500# ANSI RF
5 K
3" 600# ANSI RTJ
5 L
3" 900# ANSI RTJ
5 M
3" 1500# ANSI RTJ
5 N
3" 2500# ANSI RTJ
6 3
4" 150# ANSI RF
6 4
4" 300# ANSI RF
6 5
4" 600# ANSI RF
6 6
4" 900# ANSI RF
6 7
4" 1500# ANSI RF
6 8
4" 2500# ANSI RF
6 K
4" 600# ANSI RTJ
6 L
4" 900# ANSI RTJ
6 M
4" 1500# ANSI RTJ
6 N
4" 2500# ANSI RTJ
Torque Tube Mating Flanges ¡
T T 600# Fisher (249B/259B) in carbon steel – as per dimensions on page 18
T U
600# Fisher (249C) in stainless steel – as per dimensions on page 18
U T
600# Masoneilan flange in carbon steel – as per dimensions on page 18
U U 600# Masoneilan flange in stainless steel – as per dimensions on page 18
3
.7.3 Small Coaxial Probe
