85
57-606 ECLIPSE Model 706 Guided Wave Radar Transmitter
13 14 15 | INSERTION LENGTH
X X X
inches (012 – 240)
cm (030 – 610)
unit of measure determined by
2nd digit of model number
7 | FLANGE OPTIONS — Offset flanges are only available with small coaxial probes
0 None
1
Offset (For use with AURORA) — 4" Only available with 3rd digit P, S or T
2
Offset with
1
⁄2" NPT Vent (For use with AURORA) — 4" Only available with 3rd digit P, S or T
3
Offset with
3
⁄4" NPT Vent (For use with AURORA) — 4" Only available with 3rd digit P, S or T
6 | CONSTRUCTION CODES
0 Industrial
K ASME B31.1 (Not available with 4th and 5th digits T or U)
L ASME B31.3
M A
SME B31.3 & NACE MR0175/MR0103
N NACE MR0175/MR0103
8 | MATERIAL OF CONSTRUCTION - FLANGE/NUT/ROD/INSULATION
A 316 SS/316L SS
B Hastelloy C
C
Monel — NOT available with 3rd digit S
R 316 SS/316L SS with Carbon Steel Flange
S Hastelloy C with Carbon Steel Flange
T
Monel with Carbon Steel Flange — NOT available with 3rd digit S
9 | SPACER MATERIAL
1
TFE (+400 °F/+200 °C) — Only available with 3rd digit P or T — ε
r
≥ 1.4
2
PEEK HT — Only available with 3rd digit D (+650 °F/+345 °C) — ε
r
≥ 1.4 or S (+575 °F/+300 °C)
3
Ceramic (Temp. >+650 °F/+345 °C)—Only available with 3rd digit D — ε
r
≥ 2.0 or 3rd digit S
5
None - with metal shorting rod — ε
r
≥ 1.4 — Future
11 | PROBE SIZE/ELEMENT TYPE/FLUSHING CONNECTION
2 Small Coaxial (0.875 inches/22 mm)
12 | SPECIAL OPTIONS
0 Single Length Probe (Non-Segmented)
7 2
12 3 456 7 8 910 11 12 13 14 15
10 | O-RING MATERIALS/SEAL OPTIONS
0
Viton
®
GFLT — NOT available with 3rd digit T
2
Kalrez 4079 — NOT available with 3rd digit T
8
Aegis PF 128 (NACE) — NOT available with 3rd digit T
A
Kalrez 6375 — NOT available with 3rd digit T
B
HF Acid Probe — Only available with 3rd digit T and 8th digit C
D
None/Glass Ceramic Alloy (Dual Seal Design with annunciator fitting)
Only available with 3rd digit D or P
N
None/Glass Ceramic Alloy — Only available with 3rd digit D or P
3
.7.3 Small Coaxial Probe
c
ontinued
To Next Page
