57-606 ECLIPSE Model 706 Guided Wave Radar Transmitter
1 | TECHNOLOGY
2
| MEASUREMENT SYSTEM
3 | SPECIALTY FLEXIBLE PROBES
7 ECLIPSE GWR Probes - Model 706
A English
C Metric
5 Twin Flexible Light Duty Bulk Solids with FEP Webbing
7 Twin Flexible - 316 SS with FEP Webbing
ANSI Flanges
5 3 3" 150 lbs. ANSI RF
5 4 3" 300 lbs. ANSI RF
5 5 3" 600 lbs. ANSI RF
6 3 4" 150 lbs. ANSI RF
6 4 4" 300 lbs. ANSI RF
6 5 4" 600 lbs. ANSI RF
EN Flanges
E A DN 80, PN 16 EN 1092-1 TYPE A
E B DN 80, PN 25/40 EN 1092-1 TYPE A
E D DN 80, PN 63 EN 1092-1 TYPE B2
E E DN 80, PN 100 EN 1092-1 TYPE B2
F A DN 100, PN 16 EN 1092-1 TYPE A
F B DN 100, PN 25/40 EN 1092-1 TYPE A
F D DN 100, PN 63 EN 1092-1 TYPE B2
F E DN 100, PN 100 EN 1092-1 TYPE B2
4 5 | PROCESS CONNECTION – SIZE/TYPE (consult factory for other process connections)
7
12 3 456 7 8 910 11 12 13 14 15
¿ Confirm mounting conditions/nozzle diameter to ensure sufficient clearance.
Threaded ¿
2 1 1" NPT Thread (7yF and 7yM only)
4 1 2" NPT Thread
2 2
1" BSP (G1) Thread (7yF and 7yM only)
4 2
2" BSP (G1) Thread
3
.7.7 Twin Cable Flexible Probe
