57-606 ECLIPSE Model 706 Guided Wave Radar Transmitter
1
2 3 | BASIC MODEL NUMBER
4 | POWER
5 | SIGNAL OUTPUT
6 | SAFETY OPTIONS
706 5
7 0 6 ECLIPSE 4th Generation Guided Wave Radar (GWR) Level Transmitter
5 24 VDC, Two-Wire
1 4–20 mA with HART
2 FOUNDATION
™
fieldbus Communications
4 Modbus Communication
0 None (FOUNDATION fieldbus or Modbus) (5th digit = 2 or 4)
2 SIL 2/3 Certified - HART only (5th digit = 1)
7 | ACCESSORIES/MOUNTING
0 No Digital Display or Keypad - Integral
1 No Digital Display or Keypad - 3-foot (1 meter) remote
2 No Digital Display or Keypad - 12-foot (3.6 meter) remote
A Digital Display and Keypad - Integral
B Digital Display and Keypad - 3-foot (1 meter) remote
C Digital Display and Keypad - 12-foot (3.6 meter) remote
8 | CLASSIFICATION
0 General Purpose, Weatherproof (IP 67)
1 Intrinsically Safe (FM & CSA CL 1 Div 1, Grps A, B, C, D)
3 Explosion-proof (FM & CSA CL 1 Div 1, Grps B, C, D)
A Intrinsically Safe (ATEX/IEC Ex ia IIC T4)
B Flame-proof (ATEX/IEC Ex d ia IIC T6)
C
Non-sparking (ATEX Ex n IIC T6) /
Non-incendive (FM & CSA, CL 1 Div 2)
D Dust Ex (ATEX II)
9 | HOUSING
1 Die-cast Aluminum, Dual-compartment, 45-degree
2 Investment Cast, Stainless Steel, Dual-compartment, 45-degree
10 | CONDUIT CONNECTION
0
1
⁄2" NPT
1 M20
2
1
⁄2" NPT with sunshade
3 M20 with sunshade
123 4567 8910
3.7 Model Number
3.7.1 Transmitter
