57-606 ECLIPSE Model 706 Guided Wave Radar Transmitter
(1) Electronic Module
Digit 5 Digit 6 Replacement Part
1 2 Z31-2849-001
2 0 Z31-2849-002
(2) Display Module
Digit 5 Digit 7 Replacement Part
1 or 2
0, 1 or 2 N/A
A, B or C Z31-2850-001
(3) Wiring PC Board
Digit 5 Digit 6 Replacement Part
1 2 Z30-9165-001
2 0 Z30-9166-001
4 0 Z31-2859-001
Replacement Part
(4) O-ring
Z12-2201-237
(5) O-ring
Z12-2201-237
(6) Housing Cover
Digit 7 Digit 8 Digit 9 Replacement Part
0, 1 or 2 all
1 004-9225-002
2 004-9225-003
A, B or C
0, 1 or A
1
036-4413-005
3 036-4413-001
B, C or D 036-4413-008
0, 1, 3 or A
2
036-4413-002
B, C or D 036-4413-009
(7) Housing Cover
Digit 9 Replacement Part
1 004-9225-002
2 004-9225-003
6
7
5
2
4
1
3
RR
J
1
+
-
CURRENT LOOP
T
B
1
R
7 0 67 7 7 7 7 7 7 7
7
X = product with a non-standard customer requirement
See nameplate, always provide complete part number and
serial number when ordering spares.
0 65
Digit:
Serial Number:
Part Number:
Electronics:
123 456 89107
3.8 Parts
3
.8.1 Replacement Parts
