Magnetrol Eclipse 706GWR - Segmented Probe Options

94
57-606 ECLIPSE Model 706 Guided Wave Radar Transmitter
NOTE: Segments will be evenly divided over the length of the probe.
Probe Model
One
Segment
Two
Segments
Three
Segments
Four
Segments
Five
Segments
Six
Segments
Coaxial Models
7yD, 7yP and 7yT
(Enlarged versions only)
(3", DN 80 Process
Connections and larger)
24 – 72"
(60 – 182 cm)
48 – 144"
(120 – 365 cm)
72 – 216"
(180 – 548 cm)
96 – 288"
(240 – 731 cm)
120 – 360"
(305 – 914 cm)
144 – 396"
(365 – 999 cm)
Caged Models
7yG, 7yL and 7yJ
12 – 120"
(30 – 305 cm)
24 – 240"
(60 – 610 cm)
36 – 288"
(90 – 732 cm)
48 – 288"
(120 – 732 cm)
Not Available Not Available
3
.7.8 Segmented Probe Options
1
2th Digit of Model Number
