57-606 ECLIPSE Model 706 Guided Wave Radar Transmitter
Home Screen
M
ain Menu
D
evice Setup
Q
uick Start
Identity
B
asic Config
I
/O Config
Display Config
A
dvanced Config
Factory Config
L
evel Units:
Inches
F
eet
M
illimeters
Centimeters
M
eters
P
robe Model:
7YD Coax HTHP
7
YF Sngl Rod Tanks
7
YG Sngl Rod Cages
7YJ Sngl Rod Cages
7
YL Sngl Rod Cages
7YM Sngl Rod Tanks
7
YN Sngl Rod Tanks
7
YP Coax HP
7YS Coax Steam
7
YT Coax Std
7Y1 Sngl Flex Std
7Y2 Sngl Flex Bulk
7Y3 Sngl Flex HP
7
Y5 Twin Flex Bulk
7Y6 Sngl Flx HTHP Cage
7Y7 Twin Flex Clad
Probe Mount:
NPT
BSP
Flange
NPT/Flushing
BSP/Flushing
Flange/Flushing
Hygienic
Probe Length:
1
2 inches to 100 feet
(30 cm to 30 m)
L
evel Offset:
-25 feet to +75 feet
(
-7.6 m to 22.9 m)
Dielectric Range:
B
elow 1.7
1
.7 to 3.0
3.0 to 10
A
bove 10
4
mA Set Point (LRV):
-
25 feet to +175 feet
(-7.6 m to 53 m)
20 mA Set Point (URV):
-25 feet to +175 feet
(-7.6 m to 53 m)
Failure Alarm:
22 mA
3.6 mA
Hold
Level Units:
Inches
Feet
Millimeters
Centimeters
Meters
Probe Model:
7YD Coax HTHP
7YF Sngl Rod Std
7YG Sngl Rod Std
7YJ Sngl Rod HTHP
7YL Sngl Rod HP
7YM Sngl Rod HP
7YN Sngl Rod HTHP
7YP Coax HP
7YS Coax Steam
7YT Coax Std
7Y1 Sngl Flex Std
7Y2 Sngl Flex Bulk
7Y3 Sngl Flex HP
7Y5 Twin Flex Bulk
7Y6 Sngl Flx HTHP Cage
7Y7 Twin Flex Clad
Probe Coating: (7yF only)
None (Bare)
PFA Coated
Probe Mount:
NPT
BSP
Flange
NPT/Flushing
BSP/Flushing
Flange/Flushing
Hygienic
Probe Length:
12 inches to 100 feet
(30 cm to 30 m)
Level Offset:
-25 feet to +75 feet
(-7.6 m to 22.9 m)
Dielectric Range:
Below 1.7
1.7 to 3.0
3.0 to 10
Above 10
Home Screen
Main Menu
Device Setup
Quick Start
Identity
Basic Config
I/O Config
Display Config
Advanced Config
Factory Config
Product Name (read only)
Magnetrol S/N (read only)
Hardware Version (read only)
Firmware Version (read only)
LongTag
Measurement Type:
Level Only
Interface and Level
Volume and Level
Flow
2.6.5 Model 706 Configuration Menu — Device Setup
