Magnetrol Eclipse 706GWR - Page 83

83
57-606 ECLIPSE Model 706 Guided Wave Radar Transmitter
13 14 15 | INSERTION LENGTH
X X X
inches (012 – 396)
cm (030 – 999)
unit of measure determined by
2nd digit of model number
7 | FLANGE OPTIONS — Offset flanges are only available with small coaxial probes
0 None
6 | CONSTRUCTION CODES
0 Industrial
K ASME B31.1
L ASME B31.3
M ASME B31.3 & NACE MR0175/MR0103
N NACE MR0175/MR0103
8 | MATERIAL OF CONSTRUCTION - FLANGE/NUT/ROD/INSULATION
A 316 SS/316L SS (Probe O.D. 1.75” (45mm))
B Hastelloy C (Probe O.D. 1.93” (49mm))
C Monel (Probe O.D. 1.93” (49mm))
R 316 SS/316L SS with Carbon Steel Flange (Probe O.D. 1.75” (45 mm))
S Hastelloy C with Carbon Steel Flange (Probe O.D. 1.93” (49mm))
T Monel with Carbon Steel Flange (Probe O.D. 1.93” (49mm))
9 | SPACER MATERIAL
1
TFE (+400 °F/+200 °C) — Only available with 3rd digit P or T — ε
r
≥ 1.4
2
PEEK HT — Only available with 3rd digit D (+650 °F/+345 °C) — ε
r
≥ 1.4
3
Ceramic (High Temp. >+800 °F/+425 °C) — Only available with 3rd digit D — ε
r
≥ 2.0
4
Celazole (+800 °F/+425 °C) — Only available with 3rd digit D — ε
r
≥ 1.4
5
None - with metal shorting rod — ε
r
≥ 1.4 — Future
11 | PROBE SIZE/ELEMENT TYPE/FLUSHING CONNECTION
0 Standard Enlarged Coaxial Probe
1 Standard Enlarged Coaxial Probe with Flushing Port
12 | SPECIAL OPTIONS — See page 70
0 Single Length Probe (Non-Segmented)
1 1-piece Enlarged Segmented Probe OD=2.5”(64mm)
2 2-piece Enlarged Segmented Probe OD=2.5”(64mm)
3 3-piece Enlarged Segmented Probe OD=2.5”(64mm)
4 4-piece Enlarged Segmented Probe OD=2.5”(64mm)
5 5-piece Enlarged Segmented Probe OD=2.5"(64mm)
6 6-piece Enlarged Segmented Probe OD=2.5"(64mm)
7
12 3 456 7 8 910 11 12 13 14 15
10 | O-RING MATERIALS/SEAL OPTIONS
0
Viton
®
GFLT — Only available with 3rd digit T
2
Kalrez 4079 — Only available with 3rd digit T
8
Aegis PF 128 (NACE) — Only available with 3rd digit T
A
Kalrez 6375 — Only available with 3rd digit T
B
HF Acid Probe — Only available with 3rd digit T and 8th digit C
D
None/Glass Ceramic Alloy (Dual Seal Design with annunciator fitting)
Only available with 3rd digit D or P
N
None/Glass Ceramic Alloy — Only available with 3rd digit D or P
3
.7.2 Enlarged Coaxial Probe
c
ontinued
