57-606 ECLIPSE Model 706 Guided Wave Radar Transmitter
H
ome Screen
M
ain Menu
D
evice Setup
Q
uick Start
I
dentity
Basic Config
I
/O Config
Display Config
Advanced Config
Factory Config
P
rimary Variable
4
mA Set Pt (LRV):
-25 to +175 feet ([Upr] Level, Ifc Level)
(
-7.6 m to 53 m)
2.0 inches to 100 feet (Upr Thickness)
(
5 cm to 30 m)
0 to 9999999 gals (Volume)
0
to 9999999 cubic ft/min (Flow)
20 mA Set Pt (URV):
-
25 to +175 feet ([Upr] Level, Ifc Level)
(-7.6 m to 53 m)
2
.0 inches to 100 feet (Upr Thickness)
(5 cm to 30 m)
0 to 9999999 cf (Volume)
0
to 9999999 cfs (Flow)
F
ailure Alarm:
22 mA
3.6 mA
Hold
Damping:
0 to 10 seconds
Language:
English
French
German
Spanish
Russian
Status Symbol:
Hide
View
Long Tag:
Hide
View
PV Bar Graph:
Hide
View
Level:
Hide
View
Ifc Level:
(Interface and Level mode only)
Hide
View
Upr Thickness:
(Interface and Level mode only)
Hide
View
Volume:
(Volume and Level mode only)
Hide
View
Flow:
(Flow mode only)
Hide
View
Head:
(Flow mode only)
Hide
View
Distance:
Hide
View
% Output:
Hide
View
Analog Output:
Hide
View
NRTotalizer:
(Flow mode only)
Hide
View
R Totalizer:
(Flow mode only)
Hide
View
Upr Echo Strength:
(Interface and level mode only)
Hide
View
Ifc Echo Strength:
(Interface and level mode only)
Hide
View
Elec Temp:
Hide
View
Probe Buildup:
(Buildup Detection = On)
Hide
View
2.6.5 Model 706 Configuration Menu — Device Setup
