57-606 ECLIPSE Model 706 Guided Wave Radar Transmitter
H
ome Screen
M
ain Menu
D
evice Setup
Q
uick Start
Identity
B
asic Config
I
/O Config
Display Config
A
dvanced Config
Factory Config
F
iducial Gain:
0
to 255 (read only)
F
id Threshold Value
SZ Hysteresis (Safe Zone Hysteresis):
(
not used when Safe Zone Alarm is None)
0 to 100 feet
(
0 to 30 m)
PROBE TARGET (Compensation = Auto):
P
robe Target Mode
Off
Run
Calibrate
Targ Calib Ticks
T
arget Ticks
Elec Temp Offset
Ifc Boundary Offset
NAP Value
Factory Reset
FACTORY CALIB
(Factory password required)
Window
Fiducial Ticks
Conversion Factor
Scale Offset
2.6.5 Model 706 Configuration Menu — Device Setup
