87
57-606 ECLIPSE Model 706 Guided Wave Radar Transmitter
6 | CONSTRUCTION CODES
8 | MATERIAL OF CONSTRUCTION - MFG/NUT/ROD/INSULATION
0 Industrial
K ASME B31.1
L ASME B31.3
M ASME B31.3 & NACE MR0175/MR0103
N NACE MR0175/MR0103
9 | SPACER MATERIAL
2 PEEK HT (+650 °F/+345 °C)
3
Ceramic (High Temp.>+800 °F/+425 °C) — Only available with 3rd digit J
4
Celazole
®
(+800 °F/+425 °C) — Only available with 3rd digit J
13 14 15 | INSERTION LENGTH
X X X
inches (012 – 288)
cm (030 – 732)
unit of measure determined by
2nd digit of model number
10 | O-RING MATERIALS/SEAL OPTIONS
0
Viton
®
GFLT — NOT available with 3rd digit J or L
2
Kalrez 4079 — NOT available with 3rd digit J or L
8
Aegis PF 128 (NACE) — NOT available with 3rd digit J or L
A
Kalrez 6375 — NOT available with 3rd digit J or L
B
HF Acid Probe — Only available with 3rd digit G and 8th digit C
D
None/Glass Ceramic Alloy (Dual Seal Design with annuncia-
tor fitting) — NOT available with 3rd digit G
N
None/Glass Ceramic Alloy — NOT available with 3rd digit G
A 316 SS/316L SS
B Hastelloy C
C Monel
R 316 SS/316L SS with Carbon Steel Flange
S Hastelloy C with Carbon Steel Flange
T Monel with Carbon Steel Flange
11 | PROBE SIZE/ELEMENT TYPE/FLUSHING CONNECTION
1 Single Length Removable Probe
2 2-piece Segmented Probe
3 3-piece Segmented Probe
4 4-piece Segmented Probe
12 | SPECIAL OPTIONS — See page 94
0 None
7 0
12 3 456 7 8 910 11 12 13 14 15
7 | FLANGE OPTIONS
0 None
1
Offset (For use with AURORA)–4” Only available with 3rd digit G and J and 4th digit 6
2
Offset with
1
⁄2" NPT Vent (For use with AURORA)–4” Only available with 3rd digit G and J and 4th digit 6
3
Offset with
3
⁄4" NPT Vent (For use with AURORA)–4” Only available with 3rd digit G and J and 4th digit 6
3
.7.4 Caged Probe
c
ontinued
