57-606 ECLIPSE Model 706 Guided Wave Radar Transmitter
6 | CONSTRUCTION CODES
7 | FLANGE OPTIONS
0 Industrial
K ASME B31.1
L ASME B31.3
M ASME B31.3 & NACE MR0175/MR0103
N NACE MR0175/MR0103
0 None
12 | SPECIAL OPTIONS
0
Non-Removable Rod
Only available with PFA Coated Probes(8th digit F or P)
1
Removable Rod
NOT available with PFA Coated Probes(8th Digit F or P)
11 | PROBE SIZE/ELEMENT TYPE/FLUSHING CONNECTION
0 Standard Single Rod
13 14 15 | INSERTION LENGTH
X X X
inches (012 – 288)
cm (030 – 732)
unit of measure determined by
2nd digit of model number
8 | MATERIAL OF CONSTRUCTION - MFG/NUT/ROD/INSULATION
A 316 SS/316L SS
B Hastelloy C
C Monel
F
Faced Flange, PFA coated wetted surfaces — Only available with Digit 3rd digit F
P
PFA coated rod — Only available with Digit 3rd digit F
R 316 SS/316L SS with Carbon Steel Flange
S Hastelloy C with Carbon Steel Flange
T Monel with Carbon Steel Flange
9 | SPACER MATERIAL
0
None – NOT available with 3rd Digit N
2
PEEK HT (+650 °F/+345 °C) — Only available with 3rd digit N
3
Ceramic (High Temp.>+800 °F/+425 °C) — Only available with 3rd digit N
4
Celazole
®
(+800 °F/+425 °C) — Only available with 3rd digit N
10 | O-RING MATERIALS/SEAL OPTIONS
0
Viton
®
GFLT — NOT available with 3rd digit M or N
2
Kalrez 4079 — NOT available with 3rd digit M or N
8
Aegis PF 128 (NACE) — NOT available with 3rd digit M or N
A
Kalrez 6375 — NOT available with 3rd digit M or N
D
None/Glass Ceramic Alloy Dual Seal with annunciator
fitting — NOT available with 3rd digit F
N
None/Glass Ceramic Alloy Dual Seal — NOT available with 3rd digit F
7 0 0
12 3 456 7 8 910 11 12 13 14 15
3
.7.5 Single Rigid Rod Probe
c
ontinued
