MAN B&W 6.03
Page 1 of 4
MAN Diesel
MAN B&W S65ME-C8.2-GI
198 87 21-5.1
List of Capacities for 5S65ME-C8.2-GI-TII at NMCR
Seawater cooling Central cooling
Conventional TC High eff. TC Conventional TC High eff. TC
1 x TCA66-26
1 x A175-L37
1 x MET66MB
1 x TCA77-21
1 x A175-L37
1 x MET71MB
1 x TCA66-26
1 x A175-L37
1 x MET66MB
1 x TCA77-21
1 x A175-L37
1 x MET71MB
Pumps
Fuel oil circulation m³/h 6.7 6.7 6.7 6.7 6.7 6.7 6.7 6.7 6.7 6.7 6.7 6.7
Fuel oil supply m³/h 3.9 3.9 3.9 3.9 3.9 3.9 3.9 3.9 3.9 3.9 3.9 3.9
Jacket cooling m³/h 119 119 119 119 119 119 119 119 119 119 119 119
Seawater cooling * m³/h 441 447 450 455 458 466 438 440 441 450 451 453
Main lubrication oil * m³/h 290 280 290 290 280 290 290 280 290 290 280 290
Central cooling * m³/h - - - - - - 340 344 347 350 352 359
Scavenge air cooler(s)
Heat diss. app. kW 5,850 5,850 5,850 6,080 6,080 6,080 5,820 5,820 5,820 6,050 6,050 6,050
Central water flow m³/h ------ 209 209 209 217 217 217
Seawater flow m³/h 286 286 286 297 297 297 - - - - - -
Lubricating oil cooler
Heat diss. app. * kW 1,060 1,100 1,120 1,080 1,100 1,150 1,060 1,100 1,120 1,080 1,100 1,150
Lube oil flow * m³/h 286 284 286 290 284 289 286 284 286 290 284 289
Central water flow m³/h ------ 131 135 138 133 135 142
Seawater flow m³/h 156 161 164 158 161 169 - - - - - -
Jacket water cooler
Heat diss. app. kW 2,080 2,080 2,080 2,080 2,080 2,080 2,080 2,080 2,080 2,080 2,080 2,080
Jacket water flow m³/h 125 125 125 125 125 125 119 119 119 119 119 119
Central water flow m³/h ------ 131 135 138 133 135 142
Seawater flow m³/h 156 161 164 158 161 169 - - - - - -
Central cooler
Heat diss. app. * kW - - - - - - 8,960 9,000 9,020 9,210 9,230 9,280
Central water flow m³/h ------ 340 344 347 350 352 359
Seawater flow m³/h - - - - - - 438 440 441 450 451 453
Starting air system, 30.0 bar g, 12 starts. Fixed pitch propeller - reversible engine
Receiver volume m³ 2 x 6.5 2 x 6.5 2 x 6.5 2 x 6.5 2 x 6.5 2 x 6.5 2 x 6.5 2 x 6.5 2 x 6.5 2 x 6.5 2 x 6.5 2 x 6.5
Compressor cap. m³ 390 390 390 390 390 390 390 390 390 390 390 390
Starting air system, 30.0 bar g, 6 starts. Controllable pitch propeller - non-reversible engine
Receiver volume m³ 2 x 3.5 2 x 3.5 2 x 3.5 2 x 3.5 2 x 3.5 2 x 3.5 2 x 3.5 2 x 3.5 2 x 3.5 2 x 3.5 2 x 3.5 2 x 3.5
Compressor cap. m³ 210 210 210 210 210 210 210 210 210 210 210 210
Other values
Fuel oil heater kW 114 114 114 113 113 113 114 114 114 113 113 113
Exh. gas temp. ** °C 250 250 250 230 230 230 250 250 250 230 230 230
Exh. gas amount ** kg/h 115,804 115,804 115,804 122,965 122,965 122,965 115,804 115,804 115,804 122,965 122,965 122,965
Air consumption ** kg/s 31.5 31.5 31.5 33.5 33.5 33.5 31.5 31.5 31.5 33.5 33.5 33.5
* For main engine arrangements with built-on power take-off (PTO) of a MAN Diesel & Turbo recommended type and/or torsional
vibration damper the engine's capacities must be increased by those stated for the actual system
** ISO based
For List of Capacities for derated engines and performance data at part load please visit http://www.mandieselturbo/ceas/index.htm
Table 6.03.01e: Capacities for seawater and central systems as well as conventional and high efficiency turbochargers stated at NMCR
