WHRS generator output
Because all the components come from different
manufacturers, the final output and the system ef-
ficiency have to be calculated from case to case.
However, Table 4.05.07 shows a guidance of pos-
sible outputs based on theoretically calculated
outputs from the system.
Note 1: The above given preliminary WHRS generator outputs is based on HP service steam consump-
tion of 0.3 ton/h and LP service steam consumption of 0.7 ton/h for the ship at ISO condition.
Note 2: 75% SMCR is selected due to the EEDI focus on the engine load.
Detailed information about the different WHRS
systems is found in our publication:
Waste Heat Recovery System (WHRS)
The publication is available at
www.marine.man.eu → ’Two-Stroke’ → ’Technical
Papers’.
Guidance output of WHR for S65MC-C8.2-TII and S65ME-C8.2/-GI-TII engine rated in L
1
at ISO conditions
Cyl.
Engine power PTG STG
Full WHRS with
combined turbines
% SMCR kW kWe kWe kWe
5
100 14,350 519 718 1,180
75 10,763 330 540 785
6
100 17,220 627 920 1,422
75 12,915 403 654 949
7
100 20,090 735 1,081 1,667
75 15,068 478 771 1,115
8
100 22,960 845 1,244 1,915
75 17,220 556 891 1,283
Table 4.05.07:
Theoretically calculated outputs
