Man B&W L35MC6-TII

MAN B&W 19.10
Page 10 of 10
MAN Diesel
MAN B&W L35MC6 198 77 88-1.0
Pos. Description
Mass Dimensions (mm)
(kg) A B C D
1 Collar ring for piston 15 200 320 200 583
Fig. 19.10.10: Dimensions and masses of tools
122 66 26-9.1.0
1
A
B
C
D
