Man B&W L35MC6-TII

MAN B&W 19.10
Page 9 of 10
MAN Diesel
MAN B&W L35MC6 198 77 88-1.0
Pos. Description
Mass Dimensions (mm)
(kg) A B C D E
1 Work table for exhaust valve 180 min. 1,305 1,000 570
2 Suggested working area 1,700 2,150
Fig. 19.10.08: Dimensions and masses of tools
116 55 06-8.1.0
