Additional pages 3 112 620 en 3
GMK 4100, GMK 4100-L, GMK 5095
09.09.2009
Swing-away
lattice in box
construction
The distances are always measured from the centre of the fork elements.
• Use the connection eyes (1) on part 2.
1)
The dimensions apply to the derricking swing-away lattice.
For the inclinable swing-away lattice, the centres of gravity are about
100 mm (4.0 in) further in front.
6095 mm (240.0 in)
1)
4860 mm (191.3 in)
1)
3940 mm (155.1 in)
1)
