2.2 Swing-away lattice
Lattice extension operating instructions 3 112 441 en 2 - 3
GMK 4100/4100-L/5095
11.01.2008
2.2 Swing-away lattice
2.2.1 Assembly
Observe the notes on Assembly and Identification; à p. 2 - 1.
Section 1
17 m (56 ft) swing-away lattice
10 m (33 ft) swing-away lattice
Section 1
Section 2
