2.3 Boom extension
Lattice extension operating instructions 3 112 441 en 2 - 7
GMK 4100/4100-L/5095
11.01.2008
2.3 Boom extension
2.3.1 Assembly
Observe the notes on Assembly and Identification; à p. 2 - 1.
For GMK 4100-L and GMK 5095, only the 22 m (72 ft) boom extension is
delivered.
22 m (72 ft) boom extension
27 m (89 ft) boom extension
Section 3
(5 m (16.5 ft))
Section 1
(10 m (33 ft))
Section 2
(7 m (23 ft))
Section 3
(5 m)
(16.5 ft)
Section 4
(5 m)
(16.5 ft)
Section 1
(10 m)
(33 ft)
Section 2
(7 m)
(23 ft)
