9.4 Description of the maintenance work
9 - 6 3 112 441 en Lattice extension operating instructions
GMK 4100/4100-L/5095
11.01.2008
– Pins for the section 3 and section 4 connections; à p. 4 - 9.
– Pins on the deflection sheave;
à p. 4 - 18.
On auxiliary sin-
gle-sheave boom
top and heavy
load lattice exten-
sion
– Lubricate the pins for the connections on the left and right of the main
boom head.
9.4.2 Lubricate joints
Grease, spare
parts and tools
The following table holds only for GMK 5095:
– Grease gun
Prerequisites – The truck crane must be secured to prevent unauthorised use;
à Maintenance manual of the truck crane delivered, or:
– swing-away lattice is removed;
à p. 3 - 10.
M 12
Grease
1)
Designation
per DIN 51502
Specification
Classification
GROVE
part no.
1)
Grease KP - L2K DIN 51825 00554201
1)
à Lubricant list and lubricant use Maintenance manual GMK 5095
Designation Quantity GROVE part no.
No spare parts
