1.8 How are the operating instructions structured?
1 - 6 3 112 441 en Lattice extension operating instructions
GMK 4100/4100-L/5095
11.01.2008
1.8 How are the operating instructions structured?
In Chapter 1 you can find information and instructions concerning safety.
In Chapter 2 you can find details on operations planning, such as dimen-
sions, weight, identification and centre of gravity of the lattice extensions.
Rigging and operation with the lattice extensions are described in Chapter 3
and the following chapters.
Chapter 7 provides information on turning loads with the lattice extensions.
You can find out how to drive with the rigged crane at construction sites in
Chapter 8.
Chapter 9 describes the maintenance of the lattice extensions.
Chapter 10 contains the index.
1.9 Specifications in US units of measurement
The lattice extension lengths are specified in metric units and US units of
measurement in these operating instructions. The values for the US units of
measurement are rounded off to the nearest whole number. For this reason,
these values deviate from the specifications in the
Lifting capacity table.
The following table compares the two.
Specified length
in metric units of
measurement
Corresponding length in
US units of measure-
ment according to lifting
capacity table
Rounded off length in
US units of measure-
ment in these operating
instructions
10 m 32.8 ft 33 ft
17 m 55.8 ft 56 ft
22 m 72.2 ft 72 ft
27 m 88.6 ft 89 ft
