ELECTRICAL SYSTEM GRT8100 SERVICE MANUAL
3-18
Published 3/26/2018, Control # 596-05
Turn Signal and Transmission Shift Levers
Refer to Figure 3-11.
Removal
1. Ensure key switch has been in OFF position for 2
minutes.
2. Turn battery disconnect switch to OFF position.
3. Remove steering wheel cover (3). Use a twisting motion
by pushing on side of cap closest to you with your
thumbs while pulling on side of cap farthest from you
with your fingers.
4. Remove nut (4) from column assembly shaft (9).
Remove steering wheel (5).
5. Remove four screws (11) from dashboard cover (1).
6. Remove locking lever (15).
7. Remove four screws (14) from left side cover (16).
8. Remove left side cover (16) from steering column.
9. Disconnect wire harness from back of ignition switch
(12).
10. Remove right side cover (10) from steering column
assembly (9).
11. Tag and disconnect wire harness (not shown) from
switches (19 – 24) and turn signal indicators (2).
12. Remove dashboard cover (1) from steering column.
13. Tag and disconnect wire harnesses from turn signal
lever (18) and transmission shift lever (7).
14. Remove two screws (6) and locknuts (8). Remove turn
signal and shift lever assemblies.
Installation
1. Ensure locking pin (17) is installed in turn signal lever
assembly (18).
2. Align turn signal lever assembly (18) and transmission
shift levers assembly (7) with holes in steering column
(9). Secure levers with two screws (6) and locknuts (8).
3. Connect wire harnesses to levers (7).
4. Install switch cover (6) on steering column.
5. Install wire harnesses on switches (19 – 24) and turn
signal indicators (2) as tagged during removal.
6. Install right side cover (10) on steering column (9).
7. Connect wire harness to ignition switch (12).
8. Install left side cover (16) on steering column
overlapping right side cover.
9. Install four button head screws (14) through side covers.
10. Install dashboard cover (1) on side covers with four
button head screws (11).
11. Install lever (15) on column assembly (9).
12. Pull column assembly rubber boot up and over bottom of
side covers.
13. Install steering wheel (5). Install steering wheel nut (4).
Torque to 30 lb-ft ±4 (40 Nm ±5).
14. Install steering wheel cap (3).
15. Turn battery disconnect switch to ON position.
Check
1. Operate turn signal lever or transmission shift lever per
Operator Manual. Verify each function.
2. Troubleshoot any system or circuit malfunction not
corrected by repair or replacement of lever or related
wiring.
