Manitowoc Grove GRT8100 Service Manual

1-5
Published 3/26/2018, Control # 596-05
GRT8100 SERVICE MANUAL INTRODUCTION
1
GROVE
Table 1-1Axle Weight Distribution Table
Description
CG To CL Rear
Bogie cm (in)
Weight
kg (lb)
Front Axle
kg (lb)
Rear Axle
kg (lb)
Basic Unit
Maximum Axle Loads Allowed 31752 (70000) 31752 (70000)
Maximum Axle Loads Allowed while Towing 27216 (60000) 27216 (60000)
Maximum Tire Loads Allowed 27216 (60000) 27216 (60000)
Standard Carrier 4 x 4, + All Fluids 188.52 (74.22) 21532 (47469) 9627 (21224) 11905 (26245)
Superstructure w/Cab, Main Hoist w/Cable 78.41 (31.87) 6318 (13929) 1175 (2590) 5143 (11339)
Removable Counterweight - 22,000 lb
(standard)
-157.48 (-62.00) 10000 (22046) -3735 (8234) 13735 (30280)
Boom Assy, 2/5 Sheaves, Lift Cyl Upper Pin
& Pivot Pin
584.84 (230.25) 12099 (26673) 16782 (36997) -4683 (-10324)
Lift Cylinder & Lower Shaft 493.67 (194.36) 1169 (2577) 1369 (3017) -200 (-440)
Complete Basic Machine: 12 - 47 m (39 -
154 ft) 5-Section Boom, Cummins QSB6.7
Tier 4 final engine, 29.5x25 (34 ply) Tires,
Main Hoist w/214 m (702 ft) of 19 mm
(3/4 in) 35x7 Cable, all Fluids max fill
208.00 (81.89) 51118 (112694) 25217 (55594) 25900 (57100)
Add To Basic Unit Weight
10.1 to 17.1 m (33 to 56 ft)
Bi-Fold Manual Boom Extension
739.04 (290.96) 1324 (2919) 2321 (5116) -997 (-2197)
10.1 m (33 ft) Fixed Manual Boom Extension 824.53 (324.62) 945 (2083) 1848 (4073) -903 (-1990)
10.1 to 17.1 m (33 to 56 ft)
Bi-Fold Hydraulic Boom Extension
738.35 (290.69) 1317 (2904) 2307 (5085) -989 (-2181)
10.1 m (33 ft) Fixed Hydraulic Boom
Extension
824.36 (324.55) 938 (2068) 1834 (4043) -896 (-1975)
Boom Extension Carrier Brackets (Bolt On) 643.26 (253.25) 187 (413) 286 (630) -98 (-217)
Components for Hydraulic Boom Extension
(on boom)
978.54 (385.25) 153 (338) 356 (784) -202 (-446)
Auxiliary Boom Nose - Installed
1239.82 (488.12) 59 (130) 173 (382) -114 (-252)
11 t (12 US ton) Overhaul Ball (Swivel) - tied
to O/R Box
675.64 (266.00) 294 (648) 471 (1038) -177 (-390)
91 t (100 US ton) Hookblock (6 Sheave),
Stowed in Tray
421.64 (166.00) 658 (1451) 658 (1451) 0 (0)
81.5 t (90 US ton) Hookblock (5 Sheave),
Stowed in Tray
421.64 (166.00) 621 (1369) 621 (1369) 0 (0)
60 t (65 US ton) Hookblock (5 Sheave),
Stowed in Tray
421.64 (166.00) 581 (1281) 581 (1281) 0 (0)
45 t (50 US ton) Hookblock (3 Sheave),
Stowed in Tray
421.64 (166.00) 450 (992) 450 (992) 0 (0)
22.5 t (25 US ton) Hookblock (1 Sheave),
Stowed in Tray
421.64 (166.00) 323 (712) 323 (712) 0 (0)
Rubber mat in front stowage tray 439.42 (173.00) 25 (56) 26 (58) 0 (-2)
