Driveline Retarder 266.06 (89.00) 546 (1203) 293 (645) 253 (558)
Counterweight Stand -167.64 (-66.00) 118 (260) -47 (-103) 165 (363)
Air Conditioning - Carrier 50.80 (27.80) 9 (19) 1 (2) 8 (17)
Air Conditioning - Superstructure 70.61 (27.80) 31 (69) 5 (12) 26 (57)
360 Degree Swing Lock 261.11 (102.80) 31 (69) 20 (43) 12 (26)
Driver 225.81 (88.90) 113 (250) 61 (134) 53 (116)
Cold Weather Package - Carrier (-29°) 20.32 (8.00) 107 (236) 5 (11) 102 (225)
Cold Weather Package - Carrier (-40°) 154.94 (61.00) 168 (370) 62 (136) 106 (234)
Cold Weather Package - S/S (-29° or -40°) 146.81 (57.80) 34 (76) 12 (26) 23 (50)
CE Components - Carrier 187.96 (74.00) 47 (104) 21 (46) 26 (58)
CE Components - Superstructure 98.55 (38.8) 116 (255) 27 (60) 88 (195)
Substitutions, Deletions, and Removals from Basic Unit Weight
Sub: Aux Hoist (replace IPO Cwt with Aux
Hoist and Cable)
-147.83 (-58.20) 431 (950) -151 (-333) 582 (1283)
Sub: Removable Cwgt System - 27,000 lb
(heavy)
-154.71 (-60.91) 2255 (4971) -827 (-1824) 3082 (6795)
Sub: Tier 3 Engine -101.60 (-40.00) -197 (-435) 48 (105) -245 (-540)
Sub: Synthetic Rope on Main Hoist (220 m
(722 ft) of 22 mm (7/8 in) K100)
-76.71 (-30.20) -318 (-702) 58 (128) -376 (-830)
Sub: Synthetic Rope on Aux Hoist (220 m
(722 ft) of 22 mm (7/8 in) K100)
-163.07 (-64.20) -318 (-702) 123 (271) -441 (973)
Rem: Main Hoist Cable (214 m (702 ft) of
19 mm (3/4 in) 35x7)
-76.71 (-30.20) -388 (-856) 71 (156) -459 (-1012)
Rem: Aux Hoist Cable (153 m (502 ft) of 3/4
in 35x7)
-163.07 (-64.20) -388 (-856) 150 (331) -538 (-1187)
Description
CG To CL Rear
Bogie cm (in)
Weight
kg (lb)
Front Axle
kg (lb)
Rear Axle
kg (lb)
