Manitowoc Grove GRT9165

3-3
Published 10-01-2020 Control # 699-00
GRT9165 SERVICE MANUAL ELECTRICAL SYSTEM
3
GROVE
FIGURE 3-3
17
Side Panel
Cab Electrical Panel
1 RCL Override Switch
2 Cab Rear
3 Ground SPL-B
4 Ground SPL-A
5 Cab-to-Swivel Connector
6 Circulation Fan Connector
7 Swivel Connector
8 Superstructure A
9 Superstructure B
10 Cold Weather Module
11 Crane Star Module
12 Camera Option
13 Options
14 Wireless Remote
15 Remote Charger
16 Converter
17 D1 Connector
18 D2 Connector
19 Cab Fuse Panel
20 Electronic Control Unit (MWIOL)
21 Electronic Control Unit (MWSCM)
22 CAN-A
23 CAN-B
24 CAN-C
25 CAN-D
26 CAN-E
27 Diagnostic Connector
1
2
3
4
5
6
7 8
9
10
11
12
16
13
14
15
2
18
19
20
21
26
27
22
23
25
24
Behind Seat
10148
10147
