SUPERSTRUCTURE VALVES
Figure 2-13 and the following sections describe the hydraulic
manifold valves located in the superstructure.
FIGURE 2-13
Valve Installation - Superstructure
1 Main Directional Control Manifold Valve
2 Compact Manifold Valve
3 Accessory Manifold Valve
4 Swing Manifold Valve
5 Dual Accumulator Charge Manifold Valve
6 Check Valve
2
1
4
3
5
10097
6
