POWER TRAIN GRT9165 SERVICE MANUAL
7-8
Published 10-01-2020 Control # 699-00
3. Ensure the correct size connections are used between
the air cleaner and the engine.
4. Ensure all inlet accessories are the correct size and are
not plugged by any foreign object.
FIGURE 7-6
10182
3
1
2
6
10
12
11
4
5
7
7
7
5
1 Air Cleaner
2 TBAP Sensor
3 Clamp
4 Elbow
5 Clamp
6 Elbow
7 T-bolt Clamp
8 Muffler Clamp
9 Air Intake Tube
10 Elbow
11 Air Inlet Tube
12 Adapter
7
8
8
9
9
10183
