UNDERCARRIAGE GRT9165 SERVICE MANUAL
8-6
Published 10-01-2020 Control # 699-00
1 Rear Axle Assembly
2 Middle Axle Assembly
3 Drag Link, 1311 mm (51.6 in)
4 Drag Link, 731 mm (28.8 in)
5 Relay Arm
4
2 1
3
5
3
4
6
7
8
9
11
FIGURE 8-5
6Pin
7 Capscrew
8 Washer
9Shim
10 Rig Tool Hole
11 Rig Tool
1.5 mm
(0.06 in)
9
Looking Up
6
10
4
3
Looking Down
Forward
10221
10224
10222
10223
