GRT9165 SERVICE MANUAL MAINTENANCE AND LUBRICATION
9
Published 10-01-2020 Control # 699-00
GROVE
Boom Lubrication (Continued)
58
Boom Extension
Sheaves
Figure 9-21 — —
Every 250 hours, or
3 months of service,
whichever interval
comes first
CHECK
3 service points
CHECK sheaves
for dry points of
operation
CHECK sheaves
for grease leaks
See NOTE 49.
59
Boom Extension
Screw
Figure 9-21 A
Brush on
entire screw
BRUSH ON, as
necessary
BRUSH ON
1 service point
NOTE 49: Slowly turn the sheave, and examine it for rough or dry points of operation and grease leaks. If rough or dry
points of operation are found, then replace the sheave. If grease leaks are found, then replace the sheave.
Item
Lube Point
Description
Figure No.
Approved
Lubricant
Approximate
Capacity
Service Interval
Service
Application
TELE CYLINDER WEAR PAD
9900-19
52
BOOM EXTENSION SCREW
9900-18
59
FIGURE 9-21
57
58
53
55
56
54
55
56
BOOM EXTENSION
9900-17
