GRT9165 SERVICE MANUAL INTRODUCTION
Table 1-13 Metric Series Bearing Bolts– Untreated (black finish)
Table 1-14
Inch Series with Coarse Threads (UNC) – Untreated (black finish)
Nominal Size, Threads per
Inch, and Series
Designation
Grade
Torque (N-m)
Maximum Nominal Minimum
M20X2.5 12.9 756 727 698
M24X3 10.9 1089 1047 1005
M24X3 12.9 1306 1256 1206
M27X3 10.9 1591 1530 1469
Size Grade
Torque (ft/lb)
Maximum Nominal Minimum
1/4-20
5 9.0 8.4 7.7
8 12.5 12 11.5
5/16-18
5191817
8262524
3/8-16
5323130
8484644
7/16-14
5525048
8737067
1/2-13
5 78 75 72
8 120 115 110
9/16-12
5 114 110 106
8 161 152 143
5/8-11
5 156 150 144
8 234 225 216
3/4-10
5 270 259.5 249
8 385 370 355
7/8-9
5 416 400 384
8 615 591 567
1-8
5 606 583 560
8 929 893 857
1 1/8-7
5 813 782 751
8 1342 1288 1234
1 1/4-7
5 1141 1097 1053
8 2043 1964 1885
1 3/8-6
5 1519 1461 1403
8 2496 2396 2296
1 1/2-6
5 2028 1946.5 1865
8 3276 3150 3024
