Manitowoc Grove GRT9165 Service Manual

INTRODUCTION GRT9165 SERVICE MANUAL
1-26
Published 10-01-2020 Control # 699-00
Table 1-17 Metric Series with Fine Threads – Untreated (black finish)
M27x3
8.8 1134 1090 1046
10.9 1591 1530 1469
12.9 1910 1836.5 1763
M30x3.5
8.8 1538 1479 1420
10.9 2163 2080 1997
12.9 2595 2495 2395
M36x4
8.8 2681 2578.5 2476
10.9 3964 3812 3660
12.9 4639 4461 4283
Size
Property
Class
Torque (N-m)
Maximum Nominal Minimum
M8x1
8.8292827
10.9 41 39.5 38
12.9494745
M10x0.75
8.8575553
10.9817875
12.9969390
M10x1.25
8.8575553
10.9817875
12.9969390
M12x1
8.8 101 97.5 94
10.9 150 144 138
12.9 175 168 161
M12X1.25
8.8 100 96 92
10.9 147 141.5 136
12.9 172 165.5 159
M12x1.5*
8.8 100 96 92
10.9 140 135 130
12.9 168 162 156
M14x1.5
8.8 160 153.5 147
10.9 229 220 211
12.9 268 257 246
M16x1.5
8.8 248 238.5 229
10.9 348 335 322
12.9 418 402 386
Size
Property
Class
Torque (N-m)
Maximum Nominal Minimum
