ECODRIVE03 SMT-02VRS Replacing or Exchanging Drive Components 5-5
DOK-ECODR3-SMT-02VRS**-WA01-EN-P
Switchboard wall
Machine housing
V2 V2 V2 V2 V2
Indramat-Motor
ECO3
V2
Immediate environment requirements
Conductive contamination cannot occur when operating the control
drive (at least not with the IP 65); when installing or exchanging drive
components, non- conductive contamination or light condensation
may momentarily occur.
AP5144F1.Fh7
Barcode
0
1
2
3
4
5
6
7
8
9
0
1
2
3
4
5
6
7
8
9
H1
S1
S3 S2
Barcode
Typenschild
123456789 1234
11121314 15161718
5678
1234
1234
5678
Fig. 5-2: Dirt contamination per DIN VDE 0160
zum Austausch von Kabeln, Angaben des Maschinenherstellers
•
When replacing cables, note the instructions of the machine
manufacturer.
ATTENTION
⇒
Connect power connections only when they are dry
and clean.
Note: If a standard cable from Rexroth Indramat is not used, then
check to ensure that the cable agrees with the terminal
diagram of the machine manufacturer!
