Mannesmann ecodrive03 User Manual

ECODRIVE03 SMT-02VRS Replacing Firmware 6-7
DOK-ECODR3-SMT-02VRS**-WA01-EN-P
6 Replacing Firmware
6.1 Replacing the Parameter Module
•
Secure parameters (DriveTop)
•
Switch unit off
•
Remove programming module
•
Open the lock on the back
Push locking plate
inside to open
Ap5145f1.fh7
Fig. 6-1: Locking the programming module
•
Open the programming module
Ap5146f1.fh7
Programming module
Firmware module
Parameter module
Barcode
0
1
2
3
4
5
6
7
8
9
0
1
2
3
4
5
6
7
8
9
H1
S1
S3 S2
Barcode
H1
S1
S3 S2
0
1
2
3
4
5
6
7
8
9
0
1
2
3
4
5
6
7
8
9
ISSI
IS61C6416-20T
C2110900 9728
splSI2032
110LT48
H813A08
ESF2
SDS
Fig. 6-2:Programming module
• Connect new parameter module and old firmware module
• Close lock (switch outward)
• Insert programming module
• Switch unit on
