ECODRIVE03 SMT-02VRS Description of Diagnostic Letters B..., C..., D... and A... 4-5
DOK-ECODR3-SMT-02VRS**-WA01-EN-P
C101 Invalid communication parameter (S-0-0021)
Cause:
Communications parameters which are needed to operate the drive in
communication phase 3 are invalid.
Remedy:
A list of the invalid parameters can be seen in parameter S-0-0021, List
of invalid op. data for comm. ph. 2. The invalid parameters must be
rewritten so they are correct.
See also the functional description: "S-0-0127, C100 Communication
phase 3 transition check".
C102 Limit error communication parameter (S-0-0021)
Cause:
Communications parameters, which are needed to operate the drive in
communication phase 3, are outside their limit values.
Remedy:
A list of the invalid parameters can be seen in parameter S-0-0021, List
of invalid op. data for comm. ph. 2. The invalid parameters must be
rewritten with values between the respective min. and the max. value to
be correct.
See also the functional description: "S-0-0127, C100 Communication
phase 3 transition check"
C104 Config. IDN for MDT not configurable
Cause:
Telegram type 7 was set in parameter S-0-0015, Telegram type
parameter.
Parameters which are missing in S-0-0188, List of configurable data in
MDT are kept in
S-0-0024, Configuration list for the master data telegram.
Remedy:
•
set preferred telegram (telegram type = 0..6 )
•
You must either set a priority telegram (Telegram type = 0..6) or
provide S-0-0024, Config. list of master data telegram with
parameters. These parameters are also contained in S-0-0188, List of
configurable data in the MDT.
Note: List parameters only allowed in multiplex channel.
See also the function description: "Configuration of Telegram Contents"
