ECODRIVE03 SMT-02VRS Diagnostic Message Descriptions 1-1
DOK-ECODR3-SMT-02VRS**-WA01-EN-P
1 Diagnostic Message Descriptions
Overview of the diagnostic message descriptions
Diagnostic Message Types
Each operational state of the drive will be characterized with a diagnostic
message.
Differentiations will be made between:
•
Error diagnostic messages
•
Warning diagnostic messages
•
Command diagnostic messages
•
Drive Mode diagnostic messages
•
Operation status
Construction of a diagnostic message
A diagnostic message consists of:
•
A diagnostic number and a
•
diagnostic text
F228 Excessive Control Deviation
Diagnostic message number
Diagnostic message
Fig. 1-1: Diagnostic message with a diagnostic number and text.
For the example in the graphic, "F2" and "28" are shown alternately on the
H1-Display.
The control system can read out the diagnostic number in hexadecimal
form with the S-0-0390, Diagnostic message number parameter.
In addition, the drive allocates to the control system the diagnostic
number and diagnostic text as a string F228 Excessive deviation with
the S-0-0095, Diagnostic message parameter.
