ECODRIVE03 SMT-01VRS Description of diagnostic letters F... and E... 3-1
DOK-ECODR3-SMT-02VRS**-WA01-EN-P
3 Description of diagnostic letters F... and E...
3.1 Error diagnostic messages F...
Many areas are monitored in connection with operating modes and
parameter settings. An error message is generated if a condition is
discovered which no longer allows proper operation.
The errors are separated into four different error classes. The error class
is evident from the diagnostic message. They are determined with the
drive’s error response..
Error class : Diagnostic
Message:
Drive Reaction:
Fatal F8xx Torque free switching
Travel range F6xx Velocity command value-zero
switch
Interface F4xx In accordance with best
possible deceleration
Non-fatal F2xx In accordance with best
possible deceleration
Fig. 3-1: Error Classes and Drive Reaction
If an error state is detected in the drive then an automatic operation of
the drive’s error response will be started as long the drive is in control.
The H1 display blinks a Fx / xx.
The drive’s reaction can be parameterized by P-0-0119, Deceleration as
best as possible, with interface and non-fatal errors. At the end of each
error reaction the drive is switched off.
Errors will not be automatically deleted but must be:
•
Reset from the control through the initialization of the command
S-0-0099, Reset Class 1 Diagnostics, or
•
reset by pressing the "S1" button.
If the error state is still present then the error will be immediately detected
again.
A positive edge bit on the control enable signal is necessary in order to
turn on the drive again.
Error Classes
Drive’s Error Reaction
Reset the Error
