NOTE : "nsp" PART IS LISTED FOR REFERENCE ONLY, MARANTZ WILL NOT SUPPLY THESE PARTS.
P.C.B.
NAME
VERS.
COLOR
PART NO.
(
FOR EUR
)
PART NO.
(
MJI
)
PART NAME DESCRIPTION
POS. NO.
P114 Q101 00MHC10053090 00MHC10053090 IC NJM2068DD:MONO AN
A
P114 Q103 00MHT600121A0 00MHT600121A0 TRS. KTA1268 PNP TRANSISTOR RANK=GR
P114 Q104 00MHT800931A0 00MHT800931A0 TRS. KTC3200 NPN TRANSISTOR RANK=GR
P114 Q105 00MHT800931A0 00MHT800931A0 TRS. KTC3200 NPN TRANSISTOR RANK=GR
P114 Q106 00MHT600121A0 00MHT600121A0 TRS. KTA1268 PNP TRANSISTOR RANK=GR
P114 Q107 00MHT600121A0 00MHT600121A0 TRS. KTA1268 PNP TRANSISTOR RANK=GR
P114 Q108 00MHT800931A0 00MHT800931A0 TRS. KTC3200 NPN TRANSISTOR RANK=GR
P114 Q109 00MHT600131B0 00MHT600131B0 TRS. KTA1024 PNP TRANSISTOR RANK=Y
P114 Q110 00MHT800941B0 00MHT800941B0 TRS. KTC3206 NPN TRANSISTOR RANK=Y
P114 Q118 00MHT800931A0 00MHT800931A0 TRS. KTC3200 NPN TRANSISTOR RANK=GR
P114 Q201 00MHC10053090 00MHC10053090 IC NJM2068DD:MONO AN
A
P114 Q203 00MHT600121A0 00MHT600121A0 TRS. KTA1268 PNP TRANSISTOR RANK=GR
P114 Q204 00MHT800931A0 00MHT800931A0 TRS. KTC3200 NPN TRANSISTOR RANK=GR
P114 Q205 00MHT800931A0 00MHT800931A0 TRS. KTC3200 NPN TRANSISTOR RANK=GR
P114 Q206 00MHT600121A0 00MHT600121A0 TRS. KTA1268 PNP TRANSISTOR RANK=GR
P114 Q207 00MHT600121A0 00MHT600121A0 TRS. KTA1268 PNP TRANSISTOR RANK=GR
P114 Q208 00MHT800931A0 00MHT800931A0 TRS. KTC3200 NPN TRANSISTOR RANK=GR
P114 Q209 00MHT600131B0 00MHT600131B0 TRS. KTA1024 PNP TRANSISTOR RANK=Y
P114 Q210 00MHT800941B0 00MHT800941B0 TRS. KTC3206 NPN TRANSISTOR RANK=Y
P114 Q218 00MHT800931A0 00MHT800931A0 TRS. KTC3200 NPN TRANSISTOR RANK=GR
P114 Q301 00MHC10053090 00MHC10053090 IC NJM2068DD:MONO AN
A
P114 Q303 00MHT600121A0 00MHT600121A0 TRS. KTA1268 PNP TRANSISTOR RANK=GR
P114 Q304 00MHT800931A0 00MHT800931A0 TRS. KTC3200 NPN TRANSISTOR RANK=GR
P114 Q305 00MHT800931A0 00MHT800931A0 TRS. KTC3200 NPN TRANSISTOR RANK=GR
P114 Q306 00MHT600121A0 00MHT600121A0 TRS. KTA1268 PNP TRANSISTOR RANK=GR
P114 Q307 00MHT600121A0 00MHT600121A0 TRS. KTA1268 PNP TRANSISTOR RANK=GR
P114 Q308 00MHT800931A0 00MHT800931A0 TRS. KTC3200 NPN TRANSISTOR RANK=GR
P114 Q309 00MHT600131B0 00MHT600131B0 TRS. KTA1024 PNP TRANSISTOR RANK=Y
P114 Q310 00MHT800941B0 00MHT800941B0 TRS. KTC3206 NPN TRANSISTOR RANK=Y
P114 Q318 00MHT800931A0 00MHT800931A0 TRS. KTC3200 NPN TRANSISTOR RANK=GR
P114 Q401 00MHC10053090 00MHC10053090 IC NJM2068DD:MONO AN
A
P114 Q403 00MHT600121A0 00MHT600121A0 TRS. KTA1268 PNP TRANSISTOR RANK=GR
P114 Q404 00MHT800931A0 00MHT800931A0 TRS. KTC3200 NPN TRANSISTOR RANK=GR
P114 Q405 00MHT800931A0 00MHT800931A0 TRS. KTC3200 NPN TRANSISTOR RANK=GR
P114 Q406 00MHT600121A0 00MHT600121A0 TRS. KTA1268 PNP TRANSISTOR RANK=GR
P114 Q407 00MHT600121A0 00MHT600121A0 TRS. KTA1268 PNP TRANSISTOR RANK=GR
P114 Q408 00MHT800931A0 00MHT800931A0 TRS. KTC3200 NPN TRANSISTOR RANK=GR
P114 Q409 00MHT600131B0 00MHT600131B0 TRS. KTA1024 PNP TRANSISTOR RANK=Y
P114 Q410 00MHT800941B0 00MHT800941B0 TRS. KTC3206 NPN TRANSISTOR RANK=Y
P114 Q418 00MHT800931A0 00MHT800931A0 TRS. KTC3200 NPN TRANSISTOR RANK=GR
P114 QN27 00MHT600121A0 00MHT600121A0 TRS. KTA1268 PNP TRANSISTOR RANK=GR
P114 R104 ns
p
00MGD05180160 RES. 18 OHM +- 5% 1/6
W
P114 R105 ns
p
00MGD05333160 RES. 33K OHM +- 5% 1/6
W
P114 R106 00MNK05121020 00MNK05121020 METAL RES. 120 OHM +-5% 2W ERG2SJ121E
P114 R107 00MNK05121020 00MNK05121020 METAL RES. 120 OHM +-5% 2W ERG2SJ121E
P114 R108 00MNK05121020 00MNK05121020 METAL RES. 120 OHM +-5% 2W ERG2SJ121E
P114 R109 00MNK05151020 00MNK05151020 METAL RES. 150 OHM +-5% 2W ERG2SJ151E
P114 R110 ns
p
00MGD05101160 RES. 100 OHM +- 5% 1/6
W
P114 R111 ns
p
00MGD05682160 RES. 6.8K OHM +- 5% 1/6
W
P114 R112 ns
p
00MGD05682160 RES. 6.8K OHM +- 5% 1/6
W
P114 R115 ns
p
00MGD05330160 RES. 33 OHM +- 5% 1/6
W
P114 R116 ns
p
00MGD05330160 RES. 33 OHM +- 5% 1/6
W
P114 R117 00MNB51514240 00MNB51514240 RES. LT 150 OHM 1/6W J 2400PPM
P114 R118 00MNB51514240 00MNB51514240 RES. LT 150 OHM 1/6W J 2400PPM
P114 R119 ns
p
00MGD05334160 RES. 330K OHM +- 5% 1/6
W
P114 R120 ns
p
00MGD05334160 RES. 330K OHM +- 5% 1/6
W
P114 R121 ns
p
00MGD05682160 RES. 6.8K OHM +- 5% 1/6
W
P114 R122 ns
p
00MGD05102160 RES. 1K OHM +- 5% 1/6
W
P114 R123 00MRA01020760 00MRA01020760 TRIM. RES. VARIABLE RESISTOR 1K VERTICAL
P114 R129 00MNK05100010 00MNK05100010 METAL RES. 10 OHM +-5% 1W ERG1SJ-E
P114 R130 00MNK05100010 00MNK05100010 METAL RES. 10 OHM +-5% 1W ERG1SJ-E
P114 R132 00MBW10000130 00MBW10000130 RES. COMPO. RGC55T-0.1-OHM-KX2
P114 R133 ns
p
00MGD05152160 RES. 1.5K OHM +- 5% 1/6
W
P114 R135 ns
p
00MGD05102160 RES. 1K OHM +- 5% 1/6
W
P114 R136 ns
p
00MGD05223160 RES. 22K OHM +- 5% 1/6
W
P114 R139 ns
p
00MGD05223160 RES. 22K OHM +- 5% 1/6
W
P114 R142 00MNK05100010 00MNK05100010 METAL RES. 10 OHM +-5% 1W ERG1SJ-E
