Marantz SR9600 - Page 159

NOTE : "nsp" PART IS LISTED FOR REFERENCE ONLY, MARANTZ WILL NOT SUPPLY THESE PARTS.
P.C.B.
NAME
VERS.
COLOR
PART NO.
(
FOR EUR
)
PART NO.
(
MJI
)
PART NAME DESCRIPTION
POS. NO.
P114 R143 00MNK05100010 00MNK05100010 METAL RES. 10 OHM +-5% 1W ERG1SJ-E
P114 R144 00MNK05152020 00MNK05152020 METAL RES. 1.5K OHM +-5% 2W ERG2SJ152E
P114 R145 00MNK05152020 00MNK05152020 METAL RES. 1.5K OHM +-5% 2W ERG2SJ152E
P114 R149 ns
p
00MGD05100160 RES. 10 OHM +- 5% 1/6
W
P114 R1A1 ns
p
00MGD05330160 RES. 33 OHM +- 5% 1/6
W
P114 R1A2 ns
p
00MGD05330160 RES. 33 OHM +- 5% 1/6
W
P114 R1A5 ns
p
00MGD05154160 RES. 150K OHM +- 5% 1/6
W
P114 R1A6 ns
p
00MGD05473160 RES. 47K OHM +- 5% 1/6
W
P114 R204 ns
p
00MGD05180160 RES. 18 OHM +- 5% 1/6
W
P114 R205 ns
p
00MGD05333160 RES. 33K OHM +- 5% 1/6
W
P114 R206 00MNK05121020 00MNK05121020 METAL RES. 120 OHM +-5% 2W ERG2SJ121E
P114 R207 00MNK05121020 00MNK05121020 METAL RES. 120 OHM +-5% 2W ERG2SJ121E
P114 R208 00MNK05121020 00MNK05121020 METAL RES. 120 OHM +-5% 2W ERG2SJ121E
P114 R209 00MNK05151020 00MNK05151020 METAL RES. 150 OHM +-5% 2W ERG2SJ151E
P114 R210 ns
p
00MGD05101160 RES. 100 OHM +- 5% 1/6
W
P114 R211 ns
p
00MGD05682160 RES. 6.8K OHM +- 5% 1/6
W
P114 R212 ns
p
00MGD05682160 RES. 6.8K OHM +- 5% 1/6
W
P114 R215 ns
p
00MGD05330160 RES. 33 OHM +- 5% 1/6
W
P114 R216 ns
p
00MGD05330160 RES. 33 OHM +- 5% 1/6
W
P114 R217 00MNB51514240 00MNB51514240 RES. LT 150 OHM 1/6W J 2400PPM
P114 R218 00MNB51514240 00MNB51514240 RES. LT 150 OHM 1/6W J 2400PPM
P114 R219 ns
p
00MGD05334160 RES. 330K OHM +- 5% 1/6
W
P114 R220 ns
p
00MGD05334160 RES. 330K OHM +- 5% 1/6
W
P114 R221 ns
p
00MGD05682160 RES. 6.8K OHM +- 5% 1/6
W
P114 R222 ns
p
00MGD05102160 RES. 1K OHM +- 5% 1/6
W
P114 R223 00MRA01020760 00MRA01020760 TRIM. RES. VARIABLE RESISTOR 1K VERTICAL
P114 R229 00MNK05100010 00MNK05100010 METAL RES. 10 OHM +-5% 1W ERG1SJ-E
P114 R230 00MNK05100010 00MNK05100010 METAL RES. 10 OHM +-5% 1W ERG1SJ-E
P114 R232 00MBW10000130 00MBW10000130 RES. COMPO. RGC55T-0.1-OHM-KX2
P114 R233 ns
p
00MGD05152160 RES. 1.5K OHM +- 5% 1/6
W
P114 R235 ns
p
00MGD05102160 RES. 1K OHM +- 5% 1/6
W
P114 R236 ns
p
00MGD05223160 RES. 22K OHM +- 5% 1/6
W
P114 R239 ns
p
00MGD05223160 RES. 22K OHM +- 5% 1/6
W
P114 R242 00MNK05100010 00MNK05100010 METAL RES. 10 OHM +-5% 1W ERG1SJ-E
P114 R243 00MNK05100010 00MNK05100010 METAL RES. 10 OHM +-5% 1W ERG1SJ-E
P114 R244 00MNK05152020 00MNK05152020 METAL RES. 1.5K OHM +-5% 2W ERG2SJ152E
P114 R245 00MNK05152020 00MNK05152020 METAL RES. 1.5K OHM +-5% 2W ERG2SJ152E
P114 R249 ns
p
00MGD05100160 RES. 10 OHM +- 5% 1/6
W
P114 R2A1 ns
p
00MGD05330160 RES. 33 OHM +- 5% 1/6
W
P114 R2A2 ns
p
00MGD05330160 RES. 33 OHM +- 5% 1/6
W
P114 R2A5 ns
p
00MGD05154160 RES. 150K OHM +- 5% 1/6
W
P114 R2A6 ns
p
00MGD05473160 RES. 47K OHM +- 5% 1/6
W
P114 R304 ns
p
00MGD05180160 RES. 18 OHM +- 5% 1/6
W
P114 R305 ns
p
00MGD05333160 RES. 33K OHM +- 5% 1/6
W
P114 R306 00MNK05121020 00MNK05121020 METAL RES. 120 OHM +-5% 2W ERG2SJ121E
P114 R307 00MNK05121020 00MNK05121020 METAL RES. 120 OHM +-5% 2W ERG2SJ121E
P114 R308 00MNK05121020 00MNK05121020 METAL RES. 120 OHM +-5% 2W ERG2SJ121E
P114 R309 00MNK05151020 00MNK05151020 METAL RES. 150 OHM +-5% 2W ERG2SJ151E
P114 R310 ns
p
00MGD05101160 RES. 100 OHM +- 5% 1/6
W
P114 R311 ns
p
00MGD05682160 RES. 6.8K OHM +- 5% 1/6
W
P114 R312 ns
p
00MGD05682160 RES. 6.8K OHM +- 5% 1/6
W
P114 R315 ns
p
00MGD05330160 RES. 33 OHM +- 5% 1/6
W
P114 R316 ns
p
00MGD05330160 RES. 33 OHM +- 5% 1/6
W
P114 R317 00MNB51514240 00MNB51514240 RES. LT 150 OHM 1/6W J 2400PPM
P114 R318 00MNB51514240 00MNB51514240 RES. LT 150 OHM 1/6W J 2400PPM
P114 R319 ns
p
00MGD05334160 RES. 330K OHM +- 5% 1/6
W
P114 R320 ns
p
00MGD05334160 RES. 330K OHM +- 5% 1/6
W
P114 R321 ns
p
00MGD05682160 RES. 6.8K OHM +- 5% 1/6
W
P114 R322 ns
p
00MGD05102160 RES. 1K OHM +- 5% 1/6
W
P114 R323 00MRA01020760 00MRA01020760 TRIM. RES. VARIABLE RESISTOR 1K VERTICAL
P114 R329 00MNK05100010 00MNK05100010 METAL RES. 10 OHM +-5% 1W ERG1SJ-E
P114 R330 00MNK05100010 00MNK05100010 METAL RES. 10 OHM +-5% 1W ERG1SJ-E
P114 R332 00MBW10000130 00MBW10000130 RES. COMPO. RGC55T-0.1-OHM-KX2
P114 R333 ns
p
00MGD05152160 RES. 1.5K OHM +- 5% 1/6
W
P114 R335 ns
p
00MGD05102160 RES. 1K OHM +- 5% 1/6
W
P114 R336 ns
p
00MGD05223160 RES. 22K OHM +- 5% 1/6
W
P114 R339 ns
p
00MGD05223160 RES. 22K OHM +- 5% 1/6
W
