Marantz SR9600 - Page 161

NOTE : "nsp" PART IS LISTED FOR REFERENCE ONLY, MARANTZ WILL NOT SUPPLY THESE PARTS.
P.C.B.
NAME
VERS.
COLOR
PART NO.
(
FOR EUR
)
PART NO.
(
MJI
)
PART NAME DESCRIPTION
POS. NO.
2SC3419Y 2 PWB
(
00MWA12AJ104-
)
P144 Q211 00MHT334191Y0 00MHT334191Y0 TRS. C3419 Y 40V 0.8A PC=1.2W
(
5W
)
2SC3419Y 3 PWB
(
00MWA12AJ105-
)
P154 Q311 00MHT334191Y0 00MHT334191Y0 TRS. C3419 Y 40V 0.8A PC=1.2W
(
5W
)
2SC3419Y 4 PWB
(
00MWA12AJ106-
)
P164 Q411 00MHT334191Y0 00MHT334191Y0 TRS. C3419 Y 40V 0.8A PC=1.2W
(
5W
)
POWER AMP2 PWB
(
00MWA12AJ201-
)
P214 C151 ns
p
00MOA22602540 ELECT. CAP. 22 UF M 25V ARS-TYPE ELN
A
P214 C152 00MOF15331540 00MOF15331540 FILM CAP. APSV 331J,330PF
(
TP
)
100V PP
P214 C153 ns
p
00MOA10705020 ELECT. CAP. 100 UF M 50V RA-2
P214 C154 00MOF15332540 00MOF15332540 FILM CAP. APSV 332J 3300PF
(
TF
)
100V P
P
P214 C155 ns
p
00MOA10605020 ELECT. CAP. 10 UF M 50V RA-2
P214 C156 ns
p
00MOA10710020 ELECT. CAP. RA2-100V101MC-S1
P214 C157 ns
p
00MOA10710020 ELECT. CAP. RA2-100V101MC-S1
P214 C158 00MOF15103540 00MOF15103540 FILM CAP. APSV 103J,0.01UF
(
TP
)
100V PP
P214 C161 00MOF55100590 00MOF55100590 FILM CAP. 10PF 200V +- 5% FAS
P214 C162 00MOF55470590 00MOF55470590 FILM CAP. 47PF 200V +- 5% FAS
P214 C163 00MOF55470590 00MOF55470590 FILM CAP. 47PF 200V +- 5% FAS
P214 C198 ns
p
00MOA10702520 ELECT. CAP. 100 UF M 25V RA-2
P214 C199 ns
p
00MOA10702520 ELECT. CAP. 100 UF M 25V RA-2
P214 C251 ns
p
00MOA22602540 ELECT. CAP. 22 UF M 25V ARS-TYPE ELN
A
P214 C252 00MOF15331540 00MOF15331540 FILM CAP. APSV 331J,330PF
(
TP
)
100V PP
P214 C253 ns
p
00MOA10705020 ELECT. CAP. 100 UF M 50V RA-2
P214 C254 00MOF15332540 00MOF15332540 FILM CAP. APSV 332J 3300PF
(
TF
)
100V P
P
P214 C255 ns
p
00MOA10605020 ELECT. CAP. 10 UF M 50V RA-2
P214 C256 ns
p
00MOA10710020 ELECT. CAP. RA2-100V101MC-S1
P214 C257 ns
p
00MOA10710020 ELECT. CAP. RA2-100V101MC-S1
P214 C258 00MOF15103540 00MOF15103540 FILM CAP. APSV 103J,0.01UF
(
TP
)
100V PP
P214 C261 00MOF55100590 00MOF55100590 FILM CAP. 10PF 200V +- 5% FAS
P214 C262 00MOF55470590 00MOF55470590 FILM CAP. 47PF 200V +- 5% FAS
P214 C263 00MOF55470590 00MOF55470590 FILM CAP. 47PF 200V +- 5% FAS
P214 C298 ns
p
00MOA10702520 ELECT. CAP. 100 UF M 25V RA-2
P214 C299 ns
p
00MOA10702520 ELECT. CAP. 100 UF M 25V RA-2
P214 C351 ns
p
00MOA22602540 ELECT. CAP. 22 UF M 25V ARS-TYPE ELN
A
P214 C352 00MOF15331540 00MOF15331540 FILM CAP. APSV 331J,330PF
(
TP
)
100V PP
P214 C353 ns
p
00MOA10705020 ELECT. CAP. 100 UF M 50V RA-2
P214 C354 00MOF15332540 00MOF15332540 FILM CAP. APSV 332J 3300PF
(
TF
)
100V P
P
P214 C355 ns
p
00MOA10605020 ELECT. CAP. 10 UF M 50V RA-2
P214 C356 ns
p
00MOA10710020 ELECT. CAP. RA2-100V101MC-S1
P214 C357 ns
p
00MOA10710020 ELECT. CAP. RA2-100V101MC-S1
P214 C358 00MOF15103540 00MOF15103540 FILM CAP. APSV 103J,0.01UF
(
TP
)
100V PP
P214 C361 00MOF55100590 00MOF55100590 FILM CAP. 10PF 200V +- 5% FAS
P214 C362 00MOF55470590 00MOF55470590 FILM CAP. 47PF 200V +- 5% FAS
P214 C363 00MOF55470590 00MOF55470590 FILM CAP. 47PF 200V +- 5% FAS
P214 C398 ns
p
00MOA10702520 ELECT. CAP. 100 UF M 25V RA-2
P214 C399 ns
p
00MOA10702520 ELECT. CAP. 100 UF M 25V RA-2
P214 C805 ns
p
00MOA10701620 ELECT. CAP. 100 UF M 16V RA-2
P214 C810 ns
p
00MOA10701620 ELECT. CAP. 100 UF M 16V RA-2
P214 CN01 ns
p
00MOA47601620 ELECT. CAP. 47 UF M 16V RA-2
P214 CN02 ns
p
00MOA47601620 ELECT. CAP. 47 UF M 16V RA-2
P214 CN03 ns
p
00MOA47505020 ELECT. CAP. 4.7 UF M 50V RA-2
P214 CN04 ns
p
00MOA47602520 ELECT. CAP. 47 UF M 25V RA-2
P214 CN07 ns
p
00MOA10702520 ELECT. CAP. 100 UF M 25V RA-2
P214 CN08 ns
p
00MOA10505020 ELECT. CAP. 1 UF M 50V RA-2
P214 CN19 ns
p
00MOA10702520 ELECT. CAP. 100 UF M 25V RA-2
P214 CN20 ns
p
00MOA10505020 ELECT. CAP. 1 UF M 50V RA-2
P214 CN21 ns
p
00MOA10505020 ELECT. CAP. 1 UF M 50V RA-2
P214 CN22 ns
p
00MDK18103310 CER. CAP. 0.01UF Z 50
V
P214 CN23 ns
p
00MOA10505020 ELECT. CAP. 1 UF M 50V RA-2
P214 CN24 ns
p
00MOA10505020 ELECT. CAP. 1 UF M 50V RA-2
P214 CN27 ns
p
00MOA10505020 ELECT. CAP. 1 UF M 50V RA-2
P214 CN28 ns
p
00MOA10505020 ELECT. CAP. 1 UF M 50V RA-2
P214 CN29 ns
p
00MDK18103310 CER. CAP. 0.01UF Z 50
V
P214 CN32 00MDF15103350 00MDF15103350 FILM CAP. 0.01UF,J,M,50
V
P214 D151 ns
p
00MHD20002000 DIODE 1SS176,MA165,1SS254 30V 0.1
A
P214 D152 ns
p
00MHD20002000 DIODE 1SS176,MA165,1SS254 30V 0.1
A
P214 D153 ns
p
00MHD20002000 DIODE 1SS176,MA165,1SS254 30V 0.1
A
