Marantz SR9600 - Page 162

NOTE : "nsp" PART IS LISTED FOR REFERENCE ONLY, MARANTZ WILL NOT SUPPLY THESE PARTS.
P.C.B.
NAME
VERS.
COLOR
PART NO.
(
FOR EUR
)
PART NO.
(
MJI
)
PART NAME DESCRIPTION
POS. NO.
P214 D154 ns
p
00MHD20002000 DIODE 1SS176,MA165,1SS254 30V 0.1
A
P214 D155 00MHD30821000 00MHD30821000 ZENER DIODE 8.2V ZENER EQUIVALENT
P214 D156 00MHD30821000 00MHD30821000 ZENER DIODE 8.2V ZENER EQUIVALENT
P214 D157 ns
p
00MHD20027010 DIODE HSS81TD 150V 150MA AXIA
L
P214 D159 00MHD30431000 00MHD30431000 ZENER DIODE 4.3V ZENER EQUIVALENT
P214 D161 00MHD31601000 00MHD31601000 ZENER DIODE 16V ZENER EQUIVALENT
P214 D162 00MHD31601000 00MHD31601000 ZENER DIODE 16V ZENER EQUIVALENT
P214 D251 ns
p
00MHD20002000 DIODE 1SS176,MA165,1SS254 30V 0.1
A
P214 D252 ns
p
00MHD20002000 DIODE 1SS176,MA165,1SS254 30V 0.1
A
P214 D253 ns
p
00MHD20002000 DIODE 1SS176,MA165,1SS254 30V 0.1
A
P214 D254 ns
p
00MHD20002000 DIODE 1SS176,MA165,1SS254 30V 0.1
A
P214 D255 00MHD30821000 00MHD30821000 ZENER DIODE 8.2V ZENER EQUIVALENT
P214 D256 00MHD30821000 00MHD30821000 ZENER DIODE 8.2V ZENER EQUIVALENT
P214 D257 ns
p
00MHD20027010 DIODE HSS81TD 150V 150MA AXIA
L
P214 D259 00MHD30431000 00MHD30431000 ZENER DIODE 4.3V ZENER EQUIVALENT
P214 D261 00MHD31601000 00MHD31601000 ZENER DIODE 16V ZENER EQUIVALENT
P214 D262 00MHD31601000 00MHD31601000 ZENER DIODE 16V ZENER EQUIVALENT
P214 D351 ns
p
00MHD20002000 DIODE 1SS176,MA165,1SS254 30V 0.1
A
P214 D352 ns
p
00MHD20002000 DIODE 1SS176,MA165,1SS254 30V 0.1
A
P214 D353 ns
p
00MHD20002000 DIODE 1SS176,MA165,1SS254 30V 0.1
A
P214 D354 ns
p
00MHD20002000 DIODE 1SS176,MA165,1SS254 30V 0.1
A
P214 D355 00MHD30821000 00MHD30821000 ZENER DIODE 8.2V ZENER EQUIVALENT
P214 D356 00MHD30821000 00MHD30821000 ZENER DIODE 8.2V ZENER EQUIVALENT
P214 D357 ns
p
00MHD20027010 DIODE HSS81TD 150V 150MA AXIA
L
P214 D359 00MHD30431000 00MHD30431000 ZENER DIODE 4.3V ZENER EQUIVALENT
P214 D361 00MHD31601000 00MHD31601000 ZENER DIODE 16V ZENER EQUIVALENT
P214 D362 00MHD31601000 00MHD31601000 ZENER DIODE 16V ZENER EQUIVALENT
P214 D810 ns
p
00MHD20002710 DIODE 1D3 1A/200
V
P214 D812 ns
p
00MHD20002710 DIODE 1D3 1A/200
V
P214 DN01 ns
p
00MHD20002000 DIODE 1SS176,MA165,1SS254 30V 0.1
A
P214 DN02 00MHD30331000 00MHD30331000 ZENER DIODE MTZ J 3.3A ZENER DIODE
P214 DN05 ns
p
00MHD20027010 DIODE HSS81TD 150V 150MA AXIA
L
P214 DN06 ns
p
00MHD20027010 DIODE HSS81TD 150V 150MA AXIA
L
P214 DN07 ns
p
00MHD20027010 DIODE HSS81TD 150V 150MA AXIA
L
P214 DN08 ns
p
00MHD20027010 DIODE HSS81TD 150V 150MA AXIA
L
P214 DN09 ns
p
00MHD20027010 DIODE HSS81TD 150V 150MA AXIA
L
P214 DN10 ns
p
00MHD20027010 DIODE HSS81TD 150V 150MA AXIA
L
P214 DN11 ns
p
00MHD20027010 DIODE HSS81TD 150V 150MA AXIA
L
P214 DN14 00MHD30821000 00MHD30821000 ZENER DIODE 8.2V ZENER EQUIVALENT
P214 DN15 00MHD30471000 00MHD30471000 ZENER DIODE 4.7V ZENER EQUIVALENT
P214 J182 00MYP07003820 00MYP07003820 PLUG 9202B-1-02-
T
P214 J282 00MYP07003820 00MYP07003820 PLUG 9202B-1-02-
T
P214 J382 00MYP07003820 00MYP07003820 PLUG 9202B-1-02-
T
P214 K151 00MHK136019C0 00MHK136019C0 TRS. KIT
! 2SA1360/2SC3423 O OR
Y
P214 Q164 ns
p
ns
p
TRS. ! 2SC3423 O OR Y PIAR WITH Q165
P214 Q165 ns
p
ns
p
TRS. ! 2SA1360 O OR Y PIAR WITH Q164
P214 K152 00MHK185919C0 00MHK185919C0 TRS. KIT
! 2SA1859/C4883 O OR
Y
P214 Q162 ns
p
ns
p
TRS. ! 2SC4883 O OR Y PIAR WITH Q163
P214 Q163 ns
p
ns
p
TRS. ! 2SA1859 O OR Y PIAR WITH Q162
P214 K153 00MHK121619F0 00MHK121619F0 TRS. KIT ! 2SA1216/2SC2922 PAIR FOR Q166/Q16
7
P214 Q166 ns
p
ns
p
TRS. ! 2SC2922 17A 200W PIAR WITH Q16
7
P214 Q167 ns
p
ns
p
TRS. ! 2SA1216 17A 200W PIAR WITH Q16
6
P214 K251 00MHK136019C0 00MHK136019C0 TRS. KIT
! 2SA1360/2SC3423 O OR
Y
P214 Q264 ns
p
ns
p
TRS. ! 2SC3423 O OR Y PIAR WITH Q265
P214 Q265 ns
p
ns
p
TRS. ! 2SA1360 O OR Y PIAR WITH Q264
P214 K252 00MHK185919C0 00MHK185919C0 TRS. KIT
! 2SA1859/C4883 O OR
Y
P214 Q262 ns
p
ns
p
TRS. ! 2SC4883 O OR Y PIAR WITH Q263
P214 Q263 ns
p
ns
p
TRS. ! 2SA1859 O OR Y PIAR WITH Q262
P214 K253 00MHK121619F0 00MHK121619F0 TRS. KIT ! 2SA1216/2SC2922 PAIR FOR Q266/Q26
7
P214 Q266 ns
p
ns
p
TRS. ! 2SC2922 17A 200W PIAR WITH Q26
7
P214 Q267 ns
p
ns
p
TRS. ! 2SA1216 17A 200W PIAR WITH Q26
6
P214 K351 00MHK136019C0 00MHK136019C0 TRS. KIT
! 2SA1360/2SC3423 O OR
Y
P214 Q364 ns
p
ns
p
TRS. ! 2SC3423 O OR Y PIAR WITH Q365
P214 Q365 ns
p
ns
p
TRS. ! 2SA1360 O OR Y PIAR WITH Q364
P214 K352 00MHK185919C0 00MHK185919C0 TRS. KIT
! 2SA1859/C4883 O OR
Y
P214 Q362 ns
p
ns
p
TRS. ! 2SC4883 O OR Y PIAR WITH Q363
P214 Q363 ns
p
ns
p
TRS. ! 2SA1859 O OR Y PIAR WITH Q362
